DS6 soft starters
Soft starters
2010
CA08103002Z-EN
www.eaton.comSoft starters
DS6-340-22K-MX
DS6-340-30K-MX
DS6-340-37K-MX
General
Standards
IEC/EN 60947-4-2
IEC/EN 60947-4-2
IEC/EN 60947-4-2
Approvals
–
–
–
Climatic proofing
Damp heat, constant, according to IEC 60068-2-78, damp heat, cyclic, according to IEC 60068-2-10
Ambient temperature
°C 0 - +40, up to 60 at 1 % derating
per Kelvin temperature rise
0 -
+40, up to 60 at 1 % derating
per Kelvin temperature rise
0 -
+40, up to 60 at 1 % derating
per Kelvin temperature rise
Ambient temperature storage
°C -25 - 55
-25 - 55
-25 - 55
Installation altitude
m 0 - 1000, above that 1 % derating
per 100 m, to max. 2000 m
0 - 1000,
above that 1 % derating
per 100 m, to max. 2000 m
0 - 1000,
above that 1 % derating
per 100 m, to max. 2000 m
Mounting position
Vertical
Vertical
Vertical
Protection type (power terminals)
IP20
IP20
IP20
Protection against direct contact
Finger- and back-of-hand proof
Overvoltage category/pollution degree
II/2
II/2
II/2
Mechanical shock resistance
8
g/11 ms
8
g/11 ms
8
g/11 ms
Vibration resistance to EN 60721-3-2
g
2
M2
2
M2
2
M2
Average heat dissipation with nominal load cycle
W 7
10
13
Dimensions (W x H x D)
mm 93 x 175 x 139
93
x 175 x 139
93
x 175 x 139
Radio interference level
A1
A1
A1
Weight
kg
1.8
1.8
1.8
Main contacts
Rated operating voltage
U
e
V AC 230 - 460
230 - 460
230 - 460
Mains frequency
Hz
50/60
50/60
50/60
Rated operational current
Motor load (AC-53)
I
e
A 41
55
68
Assigned motor rating (standard connection)
230
V
P kW 11
15
15
400
V
P kW 22
30
37
480
V
P HP 30
40
50
Overload cycle to IEC/EN 60947-4-2
AC-53
41
A: AC-53a: 3 - 5; 75 - 10
55
A: AC-53a: 3 - 5; 75 - 10
68
A: AC-53a: 3 - 5; 75 - 10
Terminal capacity
Power cables
Solid
mm
2
1
x (25 - 70)
2
x (6 - 25)
1
x (25 - 70)
2
x (6 - 25)
1
x (25 - 70)
2
x (6 - 25)
Flexible with ferrule
mm
2
–
–
–
Stranded
mm
2
1
x (25 - 70)
2
x (6 - 25)
1
x (25 - 70)
2
x (6 - 25)
1
x (25 - 70)
2
x (6 - 25)
Solid or stranded
AWG 1 x (12 - 2/0)
1
x (12 - 2/0)
1
x (12 - 2/0)
Flat conductor
min.
mm 2 x 9 x 0.8
2
x 9 x 0.8
2
x 9 x 0.8
max.
mm 9 x 9 x 0.9
9
x 9 x 0.9
9
x 9 x 0.9
Tightening torque
Nm –
–
–
Control cables
Solid
mm
2
1
x (0.5 - 2.5)
2
x (0.5 - 1.0)
1
x (0.5 - 2.5)
2
x (0.5 - 1.0)
1
x (0.5 - 2.5)
2
x (0.5 - 1.0)
Flexible with ferrule
mm
2
1
x (0.5 - 1.5)
2
x (0.5 - 0.75)
1
x (0.5 - 1.5)
2
x (0.5 - 0.75)
1
x (0.5 - 1.5)
2
x (0.5 - 0.75)
Stranded
mm
2
1
x (0.5 - 1.5)
2
x (0.5 - 1.0)
1
x (0.5 - 1.5)
2
x (0.5 - 1.0)
1
x (0.5 - 1.5)
2
x (0.5 - 1.0)
Solid or stranded
AWG 1 x (21 - 14)
2
x (21 - 18)
1
x (21 - 14)
2
x (21 - 18)
1
x (21 - 14)
2
x (21 - 18)
Flat conductor
–
–
–
Tightening torque
Nm 0.4
0.4
0.4
Screwdriver
mm 0.6 x 3.5
0.6
x 3.5
0.6
x 3.5
DS6
