DS6 soft starters 9/5
System overview
3
1
2
Basic devices
DS6 soft starters 1
Soft starters for three-phase AC motors
Assigned motor rating: 18.5 to 110 kW at 400 V
Rated operating voltage: 230 to 480 V
Asymmetric trigger control for clearly improved true run behavior
(Moeller Patent: PCT/EPOO/12938)
Selection data￫Engineering - Assigned switching and
protective devices.
Ordering data￫Page 9/7
Add-on functions
Superfast semiconductor fuses 3
Fuses for protecting the DS7 soft starters from short-circuits or to
achieve type “2” coordination for external surface mounting
Selection data￫Engineering - Assigned switching and
protective devices.
Ordering data ￫Page 9/8
Fuse bases 2
For external surface mounting of the superfast semiconductor
fuse
Selection data￫Engineering - Assigned switching and
protective devices.
Ordering data ￫Page 9/8
