DS6, DS7, DM4 soft starters
2010 CA08103002Z-EN
9/3
Key to part numbers
DS6 soft starters
DS6-340-22K-MX (example)
DS 6 - 3 4 0 - 22K - M X
DS 6 3 4 0 – Variable three-digit
code
– M X
DS = Drives soft starters
Device series
6 = Generation 6
Number of phases
3 = Three-phase connection
Voltage class
4 = 400 V/480 V
Version
0
Motor rating (in kW)
x(x)(x)Ky xx = Decimal specification, whole-number component,
y = decimal place
Motor code
M = For three-phase AC motors
Code for additional functions
X = With internal bypass
DS7 soft starters
DS7-340SX081N0-N (example)
DS7 3 4 0 SX 081 N 0 - N
DS7 3 4 0 SX Variable
three-digit
code
N 0 – N
2 D
D
DS7 = Device series, Generation 7
Number of phases
3 = Three-phase mains supply voltage
Voltage class
4 = 400 V (380 V – -15 % to 480 V + +10 %)
Control voltage supply
0 = 24 V AC/DC
2 = 110/230 V AC
D = 24 V DC SmartWire-Darwin
Device version
SX = Standard soft starters with internal bypass
Rated operational current
Variable magnitude in decimal notation
Radio interference suppression filters
N = No internal radio interference
suppression filter
Protection type
0 = IP20
Options
N = No option
D = SmartWire-Darwin
DS6, DS7, DM4
