Overload relays
Overload relays
2010 CA08103002Z-EN
6/37
Dimensions
Overload relaysOverload relays Base
ZE-… ZB32-XEZ ZB65-XEZ
ZB12 ZB32
① OFF
② Reset/ON
ZB32-38
① OFF
② Reset/ON
5.5
58
= 5
45
32
49 106
>
5
b2
16.5
c2
b
a
c
b1
a1
2 x d
ZB32 ZB65
a 45 60
b 85 86
c 90.5 112
c2 3.8 4.7
a1 35 50
b1 75 75
b2 40.5 47
d M4 M5
45
27.5
39 88
84
53
34
120
a
b
45
27.5
39
102
62
42
136
a
b
45
27.5
39
102
62
2
25
42
136
120
a
b
ZE, ZB
