Electronic Overload Relays
2010
CA08103002Z-EN
www.eaton.comZEV
General
Standards
IEC/EN 60947, VDE 0660, UL, CSA
Climatic proofing
Damp heat, constant, to IEC 60068-2-78
Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature
Open
1)
°C
-25…60
8)
Enclosed
1)
°C
-25…40
8)
Storage
°C
-40 - 80
Temperature compensation
Continuous
Mounting position
Any
Weight
kg
0.257
Shock resistance half-sinusoidal shock 10 ms to IEC 60068-2-27
g
15
Protection type
IP20
Protection against direct contact when actuated from front (EN 50274)
Finger- and back-of-hand proof
Main contacts
Overload relay setting range
A
1…820
7)
Temperature compensation residual error > 40 ºC
%/
K
–
Short-circuit protection rating maximum fuse
3)
With overload relay in conjunction with a transformer
as required for contactor
Tools
Pozidriv screwdriver
Size
1
Flat-blade screwdriver
mm 0.8 x 5.5
Auxiliary and control circuits
Rated impulse withstand voltage
U
imp
V
4000
Overvoltage category/pollution degree
III/3
Terminal capacities
Solid
mm
2
1
x (0.5 - 2.5)
2
x (0.5 - 1.5)
4)
Flexible with ferrule
mm
2
1
x (0.5 - 2.5)
2
x (0.5 - 1.5)
4)
Solid or stranded
AWG 1 x (18 - 14)
Terminal screw
M3.5
Tightening torque
Nm 0.8
Tools
Pozidriv screwdriver
Size
1
Flat-blade screwdriver
mm 0.8 x 5.5
Auxiliary circuit rated insulation voltage
U
i
V AC 250
Rated operating voltage
U
e
V AC 240
Safe isolation according to EN 61140
Between the auxiliary contacts
V AC 240
5)
Conventional thermal current
I
th
A
6
Rated operational current
AC-15 N/O
120
V
I
e
A
3
6)
240
V
I
e
A
3
6)
415
V
I
e
A
–
500
V
I
e
A
–
NC
120
V
I
e
A
3
240
V
I
e
A
3
415
V
I
e
A
–
500
V
I
e
A
–
DC-13 L/R ≦ 15 ms
2)
24
V
I
e
A
1
60
V
I
e
A
–
110
V
I
e
A
–
220
V
I
e
A
–
Power consumption
P
max.
W 2.5
Short-circuit rating without welding
Max. fuse
3)
A gG/gL 6
Voltage tolerance
AC operated
x U
c
0.85…1.1
DC operated
x U
c
0.85…1.1
Thermistor protection
Total resistance (cold)
Ω
1500
Response value
Ω
2720…3680
Reset range
Ω
1500…1650
Reset time
Overload
￫Page 6/23
Thermistor tripping
5
K under response temperature
Ground fault protection
Immediate
Notes
1)
Ambient air temperature: open and enclosed operating range to IEC/EN 60947, PTB: -5°C to +50°C
2)
Rated operational current: Making and breaking conditions to DC-13, L/R constant as stated
3)
See overlay “Fuses” for short-circuit rating time/current characteristic (please enquire)
4)
Terminal capacities auxiliary and control circuits, solid, flexible with ferrules: With connection of 2 conductors only the following combinations are
permissible: 0.5 and 0.75 mm², 0.75 and 1 mm², 1 and 1.5 mm²
5)
Safe isolation: Up to 240 V depending on contact assignment between mains and outputs no potential isolation to thermistor and summation current
transformer input and current sensor (neighbouring contacts: U
s
= 127 V)
6)
Rated operational current AC-15: contacts 95/96 and 97/98 3 A (contactor control), contacts 05/06 and 07/08 1.5 A (auxiliary contacts)
7)
Overload relay main contact setting range: setting range dependant on current sensor
8)
Main contacts terminal capacity solid and stranded conductors with ferrules: When using 2 conductors use identical cross-section
Ambient temperature open and enclosed: limited readability of the LCD display at < -15°C
