Overload relays
Electronic overload relays
2010 CA08103002Z-EN
6/43
Electronicoverload relaysElectronic overload relays Electronic overload relays
ZEV ZEV + ZEV-XSW-...
Current sensors
ZEV-XSW-... ZEV-XSW-820
Core-balance transformers
SSW…
29
4.5 7.2
45
93 37 59.2 78 103
75
c1
Part no. c1
ZEV + ZEV-XSW-25 120
ZEV + ZEV-XSW-65 128
ZEV + ZEV-XSW-145 134
93
a1
4.5
a
37 35 78 103
c
3 125
~150
35
26
37 Part no. a a1 c d1 d2
ZEV + ZEV-XSW-25 45 24 50 6 11.2
ZEV + ZEV-XSW-65 70 49 58 13 19
ZEV + ZEV-XSW-145 90 68 65 21 26
8
d2
d2
35
d1
Part no. a a1 a2 b b1 c d e
SSW40-... 64 50 38 100 80 86 4.5 40
SSW65-... 75 60 43 124 100 112 4.5 65
SSW120-... 86.5 70 54.5 200 170 205 4.5 120
a1
a2
b b1
c
e
a
d
ZEV
