Motor-protective circuit-breakers PKZM01, PKZM0, PKZM4, PKE
2010
CA08103002Z-EN
www.eaton.com7/3
Ordering
Screw terminals
Max. motor rating
AC-3
Rated
uninter-
rupted
current
Setting range
Part no.
Article no.
Price
See price
list
Std. pack
Information relevant for export to
North America
Overload
releases
Short-
circuit
releases
220
V
230
V
240
V
380
V
400
V
415
V
440
V
P
P
P
I
u
I
r
I
rm
kW kW kW A
A
A
Motor-protective circuit-breakers, type “1”; and type “2” coordination
–
–
–
0.16
0.1…0.16 2.2
PKZM01-0.16
278475
1
off
Product StandardsUL508;CSA-C22.2
No. 14; IEC60947-
4-1;
CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
12528
CSA Class No.
3211-05
NA Certification UL Listed, CSA
certified
Suitable for
Branch circuit, or
suitable for group
installations
See also
￫Page 7/34
–
0.06 0.06 0.25
0.16…0.25 3.5
PKZM01-0.25
278476
0.06
0.09 0.12 0.4
0.25…0.4 5.6
PKZM01-0.4
278477
0.09
0.12 0.18 0.63
0.4…0.63 8.8
PKZM01-0.63
278478
0.12
0.25 0.25 1
0.63…1
14
PKZM01-1
278479
0.25
0.55 0.55 1.6
1…1.6
22
PKZM01-1.6
278480
0.37
0.75 1.1
2.5
1.6…2.5
35
PKZM01-2.5
278481
0.75
1.5
1.5
4
2.5…4
56
PKZM01-4
278482
1.1
2.2
3
6.3
4…6.3
88
PKZM01-6.3
278483
2.2
4
4
10
6.3…10
140
PKZM01-10
278484
3
5.5
5.5
12
8…12
168
PKZM01-12
278485
4
7.5
9
16
10…16
224
PKZM01-16
283390
5.5
9
11
20
16…20
280
PKZM01-20
283383
Product StandardsUL508;CSA-C22.2
No. 14; IEC60947-
4-1;
CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
12528
CSA Class No.
3211-05
NA Certification UL Listed, CSA
certified
5.5
12.5 12.5 25
20…25
350
PKZM01-25
288893
Notes
L
T
I
>
Accessories
Page
3
Standard auxiliary contacts
￫7/10
5
Trip-indicating auxiliary contact
￫7/12
6
Shunt release, undervoltage release
￫7/29
Phase failure sensitivity to IEC/EN 60947-4-1, VDE 0660 Part 102.
Can be snap-fitted to IEC/EN 60715 top-hat rail with 7.5 or 15 mm
height
6
3
5
3
PKZM01
