2/58 RMQ-Titan pilot devices
RMQ-Titan
2010 CA08103002Z-EN
www.eaton.comRMQ-Titan
M22-ASI-S
M22-ASI-CS
Emergency-stop connections
Connection to AS-Interface cable
Yellow plug-in terminal as insulation piercing terminal
2 cables on board
Energy supply
Completely from the AS-Interface cable 26.5 - 31.6 V DC Completely from the AS-Interface, cable 26.5 - 31.6 V DC
Fixing
RMQ-Titan front fixing
RMQ-Titan base fixing
Addressing
Via AS-Interface cable
Via AS-Interface cable
Max. total current
mA 45
45
Ambient temperature
°C -25 – +55
-25 – +55
Mechanical shock resistance
30 g/11 ms to IEC 60068-2-27
30 g/11 ms to IEC 60068-2-27
Protection type
IP20
IP00
Climatic proofing
Damp heat, constant, to IEC 60068-2-78;
Damp heat, cyclical, to IEC 60068-2-30
Damp heat, constant, to IEC 60068-2-78;
Damp heat, cyclical, to IEC 60068-2-30
Mounting position
Any
Any
Standards
EN 50178
EN 50295
EN 50178
EN 50295
Inputs
Dual-channel input (22 V/5 mA) (modulated with code
sequence) (2 RMQ-Titan M22-K01 NC contact elements)
Dual-channel input (22 V/5 mA) (modulated with code
sequence) (2 RMQ-Titan M22-K01 NC contact elements)
Outputs
1 output, normally 19 V/ 8 mA, protected against
short-circuit
1 output, normally 19 V/ 8 mA, protected against
short-circuit
Status indicators
Power AS-Interface cable
Green LED on rear
Green LED on rear
Error AS-Interface, failure of AS-Interface
master
Red LED on rear
Red LED on rear
Profile
S -7.B.E
S -7.B.E
UL-File No. 29184
Pilot Duty
General Use
Terminal capacity
Rating data for
approved types to UL/CSA
1)
RMQ16 contact elements
E10
C 300, Q 300
Cu cable min. AWG 18,
max. AWG 14
E 01
C 300, R 300
RMQ-Titan contact elements
M22-K...
M22-CK...
A 600, Q 300,
> 300 V AC
same polarity
10 A –600 V AC
1 A –250 V DC
2 x 14 - 18 AWG
2 x 12 - 22 AWG
RMQ-Titan LED elements
M22-LED...
M22-CLED...
2 x 14 - 18 AWG
2 x 12 - 22 AWG
M22-LC(H)
M22-AMC
2 x 16 - 20 AWG
2 x 16 - 20 AWG
UL 508 requirements
NEMA recommendation
UL 4X
NEMA 13
Protection types, RMQ-Titan
All front elements
M22(S)-...
●
●
Legend plates
M22S-ST...
●
●
Emergency switching off labels
M22-XAK...
M22-XZK...
M22-XBK...
M22-XYK...
●
●
●
●
●
●
●
●
Foot and palm switches
FAK-...
●
●
Signal towers
SL-...
●
–
M22?AS-Interface?N/O, M22?N/O?CS
