60 / 336
RMQ-Titan pilot devices
2010 CA08103002Z-EN
www.eaton.com2/57
AS-Interface connection
for RMQ-Titan
Adapter element for RMQ-Titan
RMQ-M1C-ASI
M22-ASI
M22-ASI-C
General
Standards
EN 50081-1
EN 50082-1
IEC/EN 60947, DIN EN 50 295
IEC/EN 60947, DIN EN 50 295
Radio interference suppression
EN 55011, EN 55022
EN 55011, EN 55022
EN 55011, EN 55022
Limit value class
A
–
–
Protection type
IP20
IP20
IP00
Climatic proofing
Damp heat, constant, to IEC 60068-2-78; Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature
Open
°C
+25 - +55
+25 - +55
+25 - +55
Shock resistance, shock duration 11 ms
g
> 30
> 30
> 30
Vibrations IEC 60068-2-27
(amplitude 1 mm)
Hz
10 - 55
–
–
Dimensions
mm 92 x 46 x 30
–
–
Weight
kg
0.1
–
–
Fixing
Front fixing for RMQ-Titan
Front fixing for RMQ-Titan
Base fixing for RMQ-Titan
Mounting position
Any
Any
Any
Power supply
Rated voltage to AS-Interface Specification V DC 26.5 - 31.6
26.5 - 31.6
26.5 - 31.6
Terminal type
–
Yellowplug-in terminal as insulation
piercing terminal
2 cables on board
Current supply
Completely from the AS-Interface
cable
Completely from the AS-Interface
cable
Completely from the AS-Interface
cable
Addressing
Via AS-Interface line connection Via AS-Interface line connection Via AS-Interface line connection
Total power consumption of the AS interface mA
–
≦ 40
≦ 40
AS-Interface
Protected against polarity reversal
Protected against polarity reversal
Protected against polarity reversal
Rated operational current at full load
mA
120
–
–
Rated operational current when idle
(no I, Q set)
mA
normally 30
–
–
LED status indication
AS-Interface voltage: green LED AS-Interface power line:
green LED on element back
AS-Interface ERROR, failure of
AS-Interface master: red LED on
element back
AS-Interface line POWER:
green LED on card
AS-Interface ERROR, failure of
AS-Interface master: red LED on
card
Inputs
Inputs, protected against short-circuit
Number 4 (1 internal + 3 external)
2 (normally 22 V/5 mA)
2 (normally 22 V/5 mA)
Voltage range
V DC 24 - 30
–
–
Rated current per input
mA
normally 3.5
–
–
Switching level, high signal
V
≧ 15
–
–
Low signal
mA
–
–
–
Length of connecting cables
cm ≦ 200
–
–
Outputs
Outputs, protected against short-circuit
Number 4 (1 internal + 3 external)
1 (normally 19 V/8 mA)
1 (normally 19 V/8 mA)
Voltage range
V DC 24 V DC (+10/-15%)
–
–
Max. current carrying capacity
All outputs
–
–
–
Σ 3 external outputs
60
–
–
Length of connecting cables
cm ≦ 200
–
–
Profile
S-7.0
S-3.A.E
S-3.A.E
Specification
2.0
2.1
2.1
Addresses
Number 31
62
62
M22-AS-Interface..., RMQ-..., AS-Interface
