RMQ-Titan pilot devices

2010 CA08103002Z-EN

2/55

Technical data

Contact elements

Double-

contact

elements

LED-

elements

Illuminated

pushbutton actu-

ators, Pushbut-

ton , Mushroom-

headed pushbut-

tons momentary

Double

actuators

Selector

switch

actuators,

Illuminated

selector

switch

actuators

General

Standards

IEC/EN 60947

VDE 0660

Lifespan, mechanical

Switch

operations

x 10

6

5

–

–

5

0.2

0.1

Operating frequency

Switch

opera-

tions/h

≦ 3600

≦ 3600

–

≦ 3600

≦ 3600

≦ 2000

Actuating force

N

5

10

–

5

5

–

Operating torque (screw terminals)

Nm

0.8

–

0.8

–

–

0.3

Protection type (IEC/EN 60529)

IP20

IP20

IP20

IP67, IP69K

IP66

IP66

Climatic proofing

Damp heat, constant as per IEC 60068-2-78

Damp heat, cyclic, to IEC 60068-2-30

Ambient temperature

Open

°C

-25 - +70

-25 - +70

-25 - +70 -25 - +70

-25 - +70

-25 - +70

Mounting position

Any

Any

Any

Any

Any

Any

Mechanical shock resistance to

IEC 60068-2-27

Shock duration 11 ms, half-sinusoidal

g

30

30

30

30

30

30

Terminal capacity

Solid

mm

2

0.75 - 2.5

0.5 - 1.5

0.75 - 2.5 –

–

–

Stranded

mm

2

0.5 - 2.5

0.5 - 1.5

0.5 - 2.5 –

–

–

Flexible with ferrule

mm

2

0.5 - 1.0

–

–

–

–

Contacts

Rated impulse withstand voltage

U

imp

V AC

6000

4000

6000

–

–

–

Rated insulation voltage

U

i

V

500

250

500

–

–

–

Overvoltage category/degree of pollution

III⁄3

III⁄3

III⁄3

–

–

–

Control circuit reliability

At 24 V DC/5 mA

H

F

Fault

probability

< 10

-7

(i.e. 1 failure

to 10

7

operations)

–

–

–

–

–

At 5 V DC/1 mA

H

F

Fault

probability

< 5 × 10

-6

(i.e. 1 failure

to 5 × 10

6

operations)

–

–

–

–

–

Max. short-circuit protective device

Fuseless

Part no.

PKZM0–10/FAZ-B6/1

PKZM0–10/

FAZ-B6/1

–

–

–

–

Fuse

gG/gL A

10

10

–

–

–

–

Switching capacity

Rated operation current

AC-15

115 V

I

e

A

6

6

–

–

–

–

230 V

I

e

A

6

6

–

–

–

–

400 V

I

e

A

4

–

–

–

–

–

500 V

I

e

A

2

–

–

–

–

–

DC-13

24 V

I

e

A

3

3

–

–

–

–

42 V

I

e

A

1.7

–

–

–

–

–

60 V

I

e

A

1.2

–

–

–

–

–

110 V

I

e

A

0.8

0.6

–

–

–

–

220 V

I

e

A

0.3

0.3

–

–

–

–

Lifespan, electrical

AC-15

230 V/0.5 A

Switch

operations

x 10

6

1.6

–

–

–

–

–

230 V/1.0 A

Switch

operations

x 10

6

1

–

–

–

–

–

230 V/3.0 A

Switch

operations

x 10

6

0.7

–

–

–

–

–

DC-13

12 V/2.8 A

Switch

operations

x 10

6

1.2

–

–

–

–

–
