3/66 Sensors
E55 Series
2010 CA08103002Z-EN
www.eaton.comInductive Sensors
InductiveSensorsE55Series
Description
① LED for output status.
② Corrosion-resistant PBT enclosure
① Sensor head fitted for lateral detection. Can be rotated 90º.
② Non-metal enclosure is corrosion-resistant.
12 mm
18 mm
30 mm
a
b
a
b
Short description
Cylinder design
Tubular Inductive Proximity Sensors
by Eaton’s electrical business are
constructed of corrosion resistant PBT
plastic. They are ideally suited for
wash down applications such as those
found in food processing plants. They
are available in 12 mm, 18 mm and
30 mm diameters. Shielded sensors
can be embedded in metallic surfaces.
Approvals
Product features
Cylinder design
• Versions for 2-wire AC voltage or
3-wire DC voltage.
• Threaded tubular enclosures in
three diameters allow easy
integration into new and existing
applications
• Nonmetallic construction offers
excellent resistance to corrosion
• All models feature an output signal
indicator light.
Short description
Rectangular design
These sensors from Eaton’s electrical
business feature PBT resin enclosures
for high resistance to corrosion.
The enclosure is sized to offer a
direct replacement for standard limit
switches. The unique sensing head is
factory assembled for top sensing, but
can be easily converted in the field to
any one of four side sensing positions.
Models are available with sensing
ranges from 15 mm to 40 mm. The
sensors can be configured for N/O or
NC operation.
Product features
Rectangular design
• Nonmetallic enclosure offers
excellent resistance to corrosion.
• Same form factor and mounting as
standard limit switches for easy
retrofit.
• Sensor head features five sensing
positions (top and all four sides) that
can be easily changed in the field.
• Long sensing ranges up to 40 mm.
