Sensors
E52 Series
2010 CA08103002Z-EN
Inductive Sensors 3/71
InductiveSensorsE52Series
Description
① Adjustable sensing head for top- and side-sensing.
②M12 Plug connector.
③ Two LEDs status indication.
b
c
a
Short description
The E52 Cube sensor from Eaton is a
powerful inductive proximity sensor. It
provides a long sensing range in a
compact, standard-conformant enclo-
sure. The outputs of this series are
self-configuring as PNP or NPN,
without the need for user intervention.
The E52 features additional outputs for
various connection types to cover
many applications with just a few
models. Separate indicator lights for
voltage and output signal simplify
installation and troubleshooting. Five
different mounting methods make
these sensors exceptionally versatile.
The E52 Cube has been developed
specially for demanding applications,
for example in car production, in bulk
material plants and in metal-process-
ing industries.
Product features
• Large measuring range up to 40 mm.
• Four-wire models feature additional
outputs (1 × NC, 1 × N/O).
• Four-wire DC models feature an
automatic configuration function for
independent NPN/PNP selection.
• Robust design featuring vibration
and impact-absorbing potting
compound.
• Ideal for extreme temperatures or
high pressure washdown environ-
ments.
Approvals
