Sensors
E55 Series
2010 CA08103002Z-EN
Inductive Sensors 3/69
InductiveSensorsE55SeriesTechnical data
E55C...L12A E55C...L12T E55C...L12T...E E55C...L18A E55C...L18T
General
Standards IEC/EN 60947-5-2
Ambient temperature °C -25 - +70 -25 - +70 -25 - +70 -25 - +70 -25 - +70
Protection type IP66 IP66 IP66 IP66 IP66
Mechanical shock resistance g 30
Shock duration 11 ms
Characteristic values
Repetition accuracy of Sn % 10 10 10 10 10
Temperature drift of Sn % 10 10 10 10 10
Switching hysteresis of Sn % 20 20 20 20 20
Rated operating voltage 20 - 250 V AC 10 - 30 V DC 10 - 30 V DC 20 - 250 V AC 10 - 30 V DC
Residual ripple of Ue % 10 10 10 10 10
Operating current in the switched state at
24 V DC
Ib mA 3 – 3 3 –
Rated operational current Ie mA 150 200 200 150 200
Voltage drop at Ie Ud V 10 8 8 10 8
Switching frequency Hz 25 2000 1000 25 1000
Switching state indication LED Red Red Red Red Red
Protective functions Short-circuit
protection
Protection
against polarity
reversal
Short-circuit
protection
Protection
against polarity
reversal
Short-circuit
protection
Protection
against polarity
reversal
Function 2-wire 3-wire 3-wire 2-wire 3-wire
Construction type
Design outer dimensions) M12 x 1 M12 x 1 M12 x 1 M18 x 1 M18 x 1
Connection options Cable open
2 m connection cable
Material plastic
E55C...L18T...E E55C...L30T E55C...L30A E55C...L30T...E E55BLT...
General
Standards IEC/EN 60947-5-2
Ambient temperature °C -25 - +70 -25 - +70 -25 - +70 -25 - +70 -25 - +70
Protection type IP66 IP66 IP66 IP66 IP67
Mechanical shock resistance g 30
Shock duration 11 ms
Characteristic values
Repetition accuracy of Sn % 10 10 10 10 10
Temperature drift of Sn % 10 10 10 10 10
Switching hysteresis of Sn % 20 20 20 20 20
Rated operating voltage 10 - 30 V DC 10 - 30 V DC 20 - 250 V AC 10 - 30 V DC 20 - 264 V AC
Residual ripple of Ue % 10 10 10 10 10
Operating current in the switched state at
24 V DC
Ib mA 3 – 3 3 3
Rated operational current Ie mA 200 200 150 200 400
Voltage drop at Ie Ud V 8 8 10 8 8
Switching frequency Hz 500 300 25 150 25
Switching state indication LED Red Red Red Red Red
Protective functions Short-circuit
protection
Protection
against polarity
reversal
Short-circuit
protection
Protection
against polarity
reversal
Short-circuit
protection
Protection
against polarity
reversal
Short-circuit
protection
Protection
against polarity
reversal
Protection
against wire
breakage
Function 3-wire 3-wire 2-wire 3-wire 2-wire
Construction type
Design (outer Dimensions) M18 x 1 M30 x 1.5 M30 x 1.5 M30 x 1.5 40 x 40 x 118
Connection options
Material
Notes Further technical data can be found in the Online Catalogue at
