3/64 Sensors

E57 Miniature Series

2010 CA08103002Z-EN

Inductive Sensors

InductiveSensorsE57MiniatureSeries

Technical data

E57-EAL..., E57-EBL...

General

Standards

IEC/EN 60947-5

Ambient temperature

°C

-25 - +70

Protection type

IP67

Mechanical shock resistance

g

30

Shock duration 11 ms

Characteristic values

Repetition accuracy of S

n

% 1

Temperature drift of S

n

% 10

Switching hysteresis of S

n

% 15

Rated operating voltage

10 - 30 V DC

Operating current in the switched state at 24 V DC

I

b

mA

10

Rated operational current

I

e

mA

200

Voltage drop at I

e

U

d

V

1.5

Switching frequency

Hz

2000

Residual current due to the load in locked state at 230 V AC or 24 V DC

I

r

mA

0.01

Switching state indication

LED Red

Protective functions

Short-circuit protection

Function

3-wire

Material

Stainless steel

Notes

Further technical data can be found in the Online Catalogue at

www.moeller.net
