3/62 Sensors
E57 Miniature Series
2010 CA08103002Z-EN
Inductive Sensors
InductiveSensorsE57MiniatureSeriesDescription
① High quality stainless steel enclosures.
②M12 plug connector available for sizes 6.5 and 8 mm.
③ Sizes 5 mm and 8 mm with thread; 4 mm and 6.5 mm without thread.
④ Size 6.5 mm supplied complete with mounting bracket.
c
b
d
a
4 mm
5 mm
6.5 mm
8 mm
Short description
Eaton’s unique inductive proximity
have been developed specially for
use in extremely small spaces. The
wide range of available models with
enclosure diameters from 8 mm
down to 4 mm covers a multitude of
application scenarios. The sensors
feature three-wire connections with
an input voltage of 10 to 30 V DC. Both
shielded and unshielded versions are
available.
Product features
• Small 4, 5, 6.5 and 8 mm diameters
for use in applications with limited
space for mounting sensors
• Stainless steel enclosure.
• All models have an output status
display.
• Short-circuit and reverse polarity
protection.
• High degree of protection IP67.
Approvals
