Sensors

E52 Series

2010 CA08103002Z-EN

Inductive Sensors

3/73

InductiveSensorsE52Series

Technical data

E52-Series

General

Standards

IEC/EN 60947-5-2

Ambient temperature

°C

-40 - +70

Protection type

IP67

Mechanical shock resistance

g

30

Shock duration 11 ms

Characteristic values

Repetition accuracy of S

n

% 2

Temperature drift of S

n

% 10

Switching hysteresis of S

n

% 15

Rated operating voltage

6 - 48 V DC

Operating current in the switched state at 24 V DC

I

b

mA

25

Rated operational current

I

e

mA

300

Voltage drop at I

e

U

d

V

2.5

Switching frequency

Hz

100

Residual current due to the load in locked state at 230 V AC or 24 V DC I

r

mA

0.15

Switching state indication

LED Red

Operating voltage display

LED Green

Protective functions

Short-circuit protection

Protection against polarity reversal

Protection against wire breakage

Function

4-wire

Design (outer dimensions)

40 x 40 x 40

Rectangular enclosure

Connection options

M12, "A"-coded

plug connectors

Material

plastic

Surface

Zinc alloy

Notes

Further technical data can be found in the Online-Catalogue

at

www.moeller.net
