3/76 Sensors
E56 Series
2010 CA08103002Z-EN
Inductive Sensors
InductiveSensorsE56SeriesTechnical data
E56ADL40S E56ADL40U E56BDL70U E56CDL100U
General
Standards IEC/EN 60947-5-2
Ambient temperature °C -25 - +70 -25 - +70 -25 - +70 -25 - +70
Protection type IP67 IP67 IP67 IP67
Characteristic values
Repetition accuracy of Sn % 2 2 2 2
Temperature drift of Sn % 10 10 10 10
Switching hysteresis of Sn % 15 15 15 15
Rated operating voltage 6 - 48 V DC 6 - 48 V DC 6 - 48 V DC 6 - 48 V DC
Operating current in the switched
state at 24 V DC
Ib mA 25 25 25 25
Rated operational current Ie mA 300 300 300 300
Voltage drop at Ie Ud V 2.5 2.5 2.5 2.5
Switching frequency Hz 100 100 20 20
Min. load current Ie mA 1 1 1 1
Residual current due to the load in
locked state at 230 V AC or 24 V DC
Ir mA 0.15 0.15 0.15 0.15
Switching state indication LED Red Red Red Red
Operating voltage display LED Red Red Red Red
Protective functions Short-circuit protection
Protection against polarity reversal
Function 4-wire 4-wire 4-wire 4-wire
Construction type
Design (outer dimensions) 79 x 79 x 39 79 x 79 x 39 109 x 110 x 41 171.5 x 171.5 x 67.4
Connection options M12, "A"-coded
plug connectors
Material plastic plastic plastic plastic
Surface PPS PPS PPS PPS
Notes Further technical data can be found in the Online Catalogue at
