3/4 Position Switches
Safety position switches
2010 CA08103002Z-EN
LS-Titan
Contact configuration Circuit
symbol
Contact travel
■ = Contact closed
□ = Contact open
Color
Enclosure
covers
Enclosure Connection
type
Part no.
Article no.
Price
See
price list
Std. pack
 Positive opening
safety function according to
IEC/EN 60947-5-1
N/O =
normally open
NC = normally
closed contact
Basic unit, expandable
Rounded plunger, IP66, IP67
– 2 NC  plastic Cage
Clamp
LS-02
266107
10 off 1) 2)
– 2 NC  Cage
Clamp
LS-02-SW
272009
10 off 1) 2)
– 2 NC  Screwed
terminal
LS-S02
106729
10 off 2)
– 2 NC  Screwed
terminal
LS-S02-SW
106782
10 off 2)
– 2 NC  metal Cage
Clamp
LSM-02
266142
2 off 1) 2)
– 2 NC  plastic
EN 50047
Form B
Cage
Clamp
LS-02A
116702
10 off 1) 2)
– 2 NC  Screwed
terminal
LS-S02A
116703
10 off 2)
1 N/O 1 NC  plastic Cage
Clamp
LS-11
266109
10 off 1) 2)
1 N/O 1 NC  Cage
Clamp
LS-11-SW
272006
10 off 1) 2)
1 N/O 1 NC  Screwed
terminal
LS-S11
106783
10 off 2)
1 N/O 1 NC  Screwed
terminal
LS-S11-SW
106807
10 off 2)
1 N/O 1 NC  metal
EN 50047
Form B
Cage
Clamp
LSM-11
266144
2 off 1) 2)
1 N/O 1 NC  plastic
EN 50047
Form B
Cage
Clamp
LS-11A
116704
10 off 1) 2)
1 N/O 1 NC  Screwed
terminal
LS-S11A
116705
10 off 2)
1 N/O 1 NC  plastic Cage
Clamp
LS-11D
266114
10 off 1) 2)
1 N/O 1 NC  Cage
Clamp
LS-11D-SW
272007
10 off 1) 2)
1 N/O 1 NC  Screwed
terminal
LS-S11D
106791
10 off 2)
1 N/O 1 NC  Screwed
terminal
LS-S11D-SW
106797
10 off 2)
1 N/O 1 NC  metal Cage
Clamp
LSM-11D
266149
2 off 1) 2)
1 N/O 1 NC  plastic Cage
Clamp
LS-11DA
292361
10 off 1) 2)
1 N/O 1 NC  plastic Screwed
terminal
LS-S11DA
106795
1 off 2)
1 N/O 1 NC  metal Cage
Clamp
LSM-11DA
292363
1 off 1) 2)
1 N/O 1 NC  plastic
EN 50047
Form B
Cage
Clamp
LS-11S
266105
10 off 1) 2)
1 N/O 1 NC  plastic
EN 50047
Form B
Cage
Clamp
LS-11S-SW
272020
10 off 1) 2)
1 N/O 1 NC  plastic
EN 50047
Form B
Screwed
terminal
LS-S11S
106798
10 off 2)
1 N/O 1 NC  plastic
EN 50047
Form B
Screwed
terminal
LS-S11S-SW
106806
10 off 2)
1 N/O 1 NC  metal
EN 50047
Form B
Cage
Clamp
LSM-11S
266140
2 off 1) 2)
Notes 1) Cage Clamp is a registered trademark of
Wago Kontakttechnik, 32432 Minden, Germany.
Accessories for the Cage Clamp terminals from Wago:
Jumper insert, grey, Wago article no. 264-402
2) Operating heads ￫Page 3/9
Information relevant for export to North America
Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 12528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP66, 67, UL/CSA Type 3R, 4X (indoor use only), 12, 13
12 22
21 11
NC 11-12
21-22 NC
Zw= 4.5mm
3.0
0 3.0 6.1
11-12
21-22
0 6.1 2.0
4.0
Zw (11-12)= 3.3mm
Zw (21-22)= 5.3mm
NC
NC
14 22
21 13
13-14
21-22
NO
NC
Zw= 4.5mm
3.0
0 4.3 6.1
13-14
21-22
0 6.1 3.0
1.0
Zw= 2,3mm
NO
NC
15 27
28 16
NC 15-16
27-28 NO
Zw= 4.5mm
2.1
0 3.0 6.1
15
16 28
27
NC 15-16
27-28 NO
2.1
0 4.0 6.1
ZW= 5.5mm
14 22
21 13
13-14
13-14
21-22
21-22
Zw= 5.5mm
1.6
0 3.0 6.1
