Position Switches
Safety position switches
2010 CA08103002Z-EN
www.eaton.comLS-Titan
3/3
LS-TitanSafetyposition switches
Ordering
Contact configuration
Circuit
symbol
Contact travel
■ = Contact closed
□ = Contact open
Color
Enclosure
cover
Part no.
Article no.
Price
See price
list
Std. pack
Safety function
safety function to
IEC/EN 60947-5-1
N/O =
normally open
contact
NC =
normally
closed contact
Basic unit, expandable
Operating point electronically adjustable, IP66, IP67
Basic unit
Visible status display, comparable with positive opening function
Partly short-circuit-proof, restart after reset
1 N/O
1 NC
LSE-11
266121
2 off
1)
–
2 NC
LSE-02
266122
2 off
1)
Notes
Information relevant for export to North America
Product Standards
IEC/EN 60947-5; UL 508;
CSA-C22.2 No. 14; CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
12528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Degree of Protection
IEC: IP66, 67, UL/CSA Type 3R,
4X (indoor use only), 12, 13
1)
Operating heads ￫Page 3/9
electron.
+U
e
Q1
0V
Q2
Q1
Q2
0.5
5.5
default= 3.0
6.1
0
Q1
0V
Q2
+U
e
electron.
Q1
Q2
0.5
5.5
default= 3.0
6.1
0
LSE-11 and LSE-02: Individual operating point adjustment:
The following applies to LSE-11 and LSE-02: ensure that the power supply operates correctly when
setting the operating point.
1 s
f
max
F
2 N
set
set
adjust
fix
LED
Circuit example of series connection:
LSE-11 and LSE-02 can be used in safety-oriented circuits.
S1 is connected to 24 V DC
S2, S3 each switch with a delay of 0.7 s
R1, R2 e.g. series resistor element M22-XLED60 (2820 Ω/0.5 W)
+ 24 V
0 V
LS-..
K1
R1
S4
LSE-11
S1
Q1
Q2
0V
0V
0V
+Ue
+Ue
+Ue
LSE-11
S2
Q1
Q2
R2
LSE-11
S3
Q1
Q2
