SLTechnical data
SL signal towers
General
Standards IEC/EN 60947, VDE 0660
Protection type,
IEC/EN 60529
IP54, IP65 with SL-IP65 gasket, IP20 with acoustic module SL-A
Climatic proofing Damp heat, constant as per IEC 60068-2-78
Damp heat, cyclic, to IEC 60068-2-30
Mounting position Any
Mechanical shock resistance to IEC 60068-2-27
Shock duration 11 ms, half-sinusoidal
g > 15
Terminal capacity
Solid mm 2 0.75 - 2.5
Stranded mm 2 0.5 - 2.5
Contacts
Rated impulse withstand voltage Uimp V AC 4000
Rated insulation voltage Ui V 250
Overvoltage category/pollution degree III/3
SL-B-ASI base module for signal towers
General
Connection to AS-Interface cable Screw terminal on printed circuit board
Addressing Via connection to AS-Interface cable
Maximum total current mA ≦ 250
Energy supply Completely from the AS-Interface cable
Ambient temperature °C -25 - +55
Status LEDs on the printed circuit board Status. Output Q0/function module position 1: green
Status. Output Q1/function module position 2: green
Status. Output Q2/function module position 3: green
AS-Interface power line: green
AS-Interface error, AS-Interface master failure: red
Profile S-9.A.E
