NH Metal Cased Range
NH806
NHRS4506
NHRS12SLM
NHRS10SSLMHI
MAIN SWITCH
CAT REF MS RATING *WAYS + DIN MODULES
NH206/40 40A 2
NH206/63 63A 2
NH506 100A 5
NH806 100A 8
NH1106 100A 11
NH1406 100A 14
NH1906 100A 19
NH506+3 100A 5 3
NH806+3 100A 8 3
NH806+6 100A 8 6
NH1106+3 100A 11 3
SPLIT LOAD
CAT REF RCD RATING MCB WAYS MS RATING *WAYS
NHRS2406 80A 30mA 2 100A 4
NHRS3306 80A 30mA 3 100A 3
NHRS4206 80A 30mA 4 100A 2
NHRS5406 80A 30mA 5 100A 4
NHRS4506 80A 30mA 4 100A 5
NHRS3606 80A 30mA 3 100A 6
NHRS6306 80A 30mA 6 100A 3
NHRS3906 80A 30mA 3 100A 9
NHRS4806 80A 30mA 4 100A 8
NHRS6606 80A 30mA 6 100A 6
NHRS5706 80A 30mA 5 100A 7
NHRS7506 80A 30mA 7 100A 5
NHRS8406 80A 30mA 8 100A 4
NHRS9306 80A 30mA 9 100A 3
NHRS12506 80A 30mA 12 100A 5
NHRS11606 80A 30mA 11 100A 6
NHRS10706 80A 30mA 10 100A 7
NHRS61106 80A 30mA 6 100A 11
NHRS71006 80A 30mA 7 100A 10
NHRS9806 80A 30mA 9 100A 8
NHRS8906 80A 30mA 8 100A 9
NHRS51206 80A 30mA 5 100A 12
FLEXIBLE SPLIT LOAD CONSUMER UNITS
CAT REF
RCD RATING MCB WAYS MS RATING
*
WAYS
*
WAYS
MIN MAX MIN MAX TOTAL
NHRS6SLM 80A 30mA 2 4 100A 2 4 6
NHRS9SLM 80A 30mA 3 6 100A 3 6 9
NHRS12SLM 80A 30mA 3 9 100A 3 9 12
NHRS17SLM 80A 30mA 5 12 100A 5 12 17
SPLIT LOADWITH DIN RAIL ACCESSORY SECTION
CAT REF
RCD RATING MCB WAYS MS RATING
*
WAYS
No of MODULE WAYS
NHRS5606+6 80A 30mA 6 100A 5 6
NHRS7706+3 80A 30mA 7 100A 7 3
100mA available to order
HIGH INTEGRITY
CAT REF
30mA 30mA MS MS
RCDWAYS RCD WAYS RATING WAYS
*
MCB MCB TOTAL
NHRS23206 2 3 100A 2 7
NHRS44206 4 4 100A 2 10
NHRS43306 4 3 100A 3 10
NHRS33406 3 3 100A 4 10
NHRS76206 7 6 100A 2 15
NHRS66306 6 6 100A 3 15
NHRS46506 4 6 100A 5 15
NHRS55506 5 5 100A 5 15
NHRS45606 4 5 100A 6 15
NHRS7SSLMHI 1 to 4 1 to 4 100A 1 to 4 7
NHRS10SSLMHI 2 to 5 2 to 5 100A 2 to 5 10
NHRS15SSLMHI 2 to 9 2 to 9 100A 2 to 9 15
Flush mounting consumer units available to order.
Suffix Catalogue Reference with
/FLU
eg:
NHRS6606/FLU
* RCBOs or MCBs may be fitted to unprotected ways depending upon the
installation requirements see page 59.
