NH Insulated Range
NH704IP
NHIIX6604
DUAL TARIFF 100A MAIN SWITCH AND 100A MAIN SWITCH
CAT REF MS RATING *WAYS MS RATING *WAYS
NHIIX5404 100A 5 100A 4
NHIIX4504 100A 4 100A 5
NHIIX3904 100A 3 100A 9
NHIIX4804 100A 4 100A 8
NHIIX7504 100A 7 100A 5
NHIIX6604 100A 6 100A 6
NHIIX5704 100A 5 100A 7
NHIIX9804 100A 9 100A 8
NHIIX8904 100A 8 100A 9
NHIIX11604 100A 11 100A 6
NHIIX51204 100A 5 100A 12
DUALTARIFF 100A MAIN SWITCHAND 100A 30mA RCD MAIN SWITCH
CAT REF RCD RATING MCB WAYS MS RATING *WAYS
NHRSX5704 100A 30mA 5 100A 7
NHRSX6604 100A 30mA 6 100A 6
NHRSX7504 100A 30mA 7 100A 5
NHRSX8904 100A 30mA 8 100A 9
NHRSX9804 100A 30mA 9 100A 8
IP65 CONSUMER UNITSWITH MAIN SWITCH
CAT REF MS RATING *WAYS
=
NH304IP 63A 3
NH704IP 100A 7
NH1004IP 100A 10
=
2 module wide RCBOs only
IP65 CONSUMER UNITSWITH RCD INCOMER
CAT REF RCD RATING MCB WAYS
NHRS304IP 40A 30mA 3
NHRS704IP 80A 30mA 7
NHRS1004IP 80A 30mA 10
NH HOUSE BUILDERS CONSUMER UNITS
During the construction phase of a domestic property, house developers may need to have the facility to lock off
the visor and restrict the access to the consumer unit. This will be inline with their specific Health and Safety
procedures and requirements on the construction site.
Wylex have produced a range of High Integrity ‘flexible’ consumer units that are pre drilled and blanked ready to
be fitted with a NHLDK visor locking kit andWPL padlock if required. When the property is handed over for sale
the visor locking kit is easily removed by the electrical contractor, returning the consumer unit back to its original
design allowing complete access to the main isolator and protective devices for the house owner.
NH HOUSE BUILDERS CONSUMER UNITS
CAT REF
PRODUCT
NHP-7HIFWLK
7 way High Integrity, lockable ready
NHP-10HIFWLK
10 way High Integrity, lockable ready
NHP-15HIFWLK
15 way High Integrity, lockable ready
NHLDK
Visor locking kit
WPL
Padlock for NHLDK
We strongly recommend that with a modified lockable visor consumer
units a separate accessible point of isolation is available for emergencies
e.g. an RECSW2S isolation switch or emergency push button isolator. It
is the responsibility of the installer to ensure compliance with all relevant
regulations and Health & Safety requirements of the construction site /
building developer. See page 62.
