MASTERColour CDM-Rm Mini
D
C1
C
A
A C C1 D
max. nom. max. nom.
59 62.75 60.9 50
Product Description
•The easy way to reflect more sparkle
•The new Philips MASTERColour CDM-R
mini brings trusted MASTERColour quality
to 50 mm reflector lamps with the superior
output and colour stability to create the right
atmosphere to match your customers’ retail
brand and positioning
Product Benefits
•The miniaturized 50 mm CDM reflector
lamp makes it possible to use the smaller
fixtures and has less clutter in the ceiling
•Suitable for open luminaries, Easy installation
and easy maintenance
•Saves up to 60% energy compared to low
voltage halogen lamps. Relatively low heat
output
•This lamp gives the crisp white lighting e ect
with excellent colour stability
Product Features
•Miniatuzied 50 mm CDM reflector lamp
•High beam intensity
•Long lamp lifetime compared to halogen
lamps
•Twist and lock system
Environment
•Good environmental choice because of high
energy e ciency and long reliable life
•The product is certified by Philips Green
Flagship
•The product is RoHS compliant
•The product is covered by WEEE
Application
•Miniaturized crisp white light system for
superior accent and general lighting in shops
Warnings and Safety
•Use only with electronic control gear
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
MASTERColour CDM-Rm Mini GX10
Wattage/
Colour Code
Colour
Tempera-
ture
Luminous
Intensity
Life to 10%
failures
Life to 50%
failures
Burning
Position
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(°) (K) (cd) (h) (h)
20W/830 10 3,000 13,500 10,000 15,000 any A 1CT / 12 12 20CDMRM83010 202745 00 yes
20W/830 25 3,000 4,500 10,000 15,000 any A 1CT / 12 12 20CDMRM83025 203018 00 yes
20W/830 40 3,000 2,100 10,000 15,000 any A 1CT / 12 12 20CDMRM83040 203032 00 yes
MASTERColour CDM-R
D
C
Dim. C D
no. nom. nom.
1 92 64
D
C
Dim. C D
no. nom. nom.
2 120 95
Product Description
•Range of compact, high-e ciency, discharge
reflector lamps with a stable colour over
lifetime and a crisp, sparkling light
Product Benefits
•High lamp e cacy results in low operating
costs and low heat generation
•Long lamp life compared with incandescent
and halogen lamps
•Stable colour impression over lifetime
•Unique design increases flexibility in applica-
tion and allows powerful accents from small,
unobtrusive luminaires
•Simplified luminaire design because CDM-R
lamps can be used in open luminaires
•Relatively low heat output enhances comfort
for shoppers and sta
•Integrated UV-Block shield reduces fading
risks
Product Features
•Warm or cool white colour impression with
good colour rendering
•High beam intensities are achieved very easy
and e ciently from these compact reflector
lamps
Environment
•This product is RoHS compliant
•This product is covered by WEEE
Application
•Shops and shop windows, o ces and public
buildings
•Decorative outdoor: floodlighting and
pedestrian areas
Warnings and Safety
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
•Use only with electronic control gear. Col-
our 830 lamps may also use electromagnetic
gear.
