MASTERColour CDM-Tm Mini
Dim. C D L O
no. max. max. nom. nom.
1 52 11.2 22.6 3
2 52 11.2 22.6 4
Product Description
•Miniature, single-ended ceramic metal halide
lamp
•PGJ5 twist-lock lamp base
Product Benefits
•Stable colour impression over lifetime
•High e cacy for low operating costs and low
heat generation
•Long life compared with halogen lamps
•Relatively low heat output enhances comfort
for shoppers and sta
•Mechanical retrofit in halogen capsule
(GY6.35) luminaires (same light centre
length). For full retrofit gear and lampholder
also need to be exchanged
•UV Block for reduced fading risk of
merchandise
Product Features
•Crisp, sparkling light for a comfortable
atmosphere
•Low heat generation
•Warm white colour impression
•Good colour rendering
•Miniature size allows design of very compact
luminaires with high beam intensities for
mounting close to illuminated object
•Easy replacement due to robust twist-lock
socket
•Universal burning position
Environment
•This product is RoHS compliant
•This product is covered by WEEE
Application
•Accent and display lighting with a sparkling
e ect
•Decorative outdoor floodlighting
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•Use only with electronic control gear
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
•For 20 W PGJ5 lamp, use only Philips
electronic control gear HID PV mini PGJ5
22 W
•For 35 W PGJ5 lamp, use only Philips
electronic control gear HID PV mini 35 W
MASTERColour CDM-Tm Mini PGJ5
Wattage/
Colour Code
Colour
Tempera-
ture
Lamp
Luminous
Flux EL
Life to 10%
failures
Life to 50%
failures
Burning
Position
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8711500...
(K) (lm) (h) (h)
20W/830 3,000 1,650 10,000 12,000 any A+ 1 1CT / 12 12 20CDMTM830 20751715 yes
35W/930 3,000 3,000 10,000 12,000 any A+ 2 1CT / 12 12 35CDMTM930 21149115 yes
