MASTERColour CDM-TD
D
C
O
Dim. C D O
no. max. max. nom.
1 119.63 22 8
2 119.63 22 7
3 137.43 25 10
Beautiful sparkle, reliable life
Range of double-ended, compact, high-
e ciency, discharge lamps with a stable colour
over lifetime and a crisp, sparkling light
Product Benefits
•Stable colour impression over lifetime
•High lamp e cacy results in low operating
costs and low heat generation. Provides
better operating costs and improved light
quality versus standard quartz metal halide
(MHN/W-TD)
•Long lamp life compared with incandescent,
halogen and quartz metal halide (MHN/
W-TD) lamps
•Relatively low heat output enhances comfort
for shoppers and sta
•All types are UV-Block for reduced fading
risks
Product Features
•Warm or cool white colour impression
•Colour rendering good to excellent
•Retrofit in double-ended luminaires for
quartz metal halide lamps (MHN/W-TD),
thereby allowing to reduce operating costs
and improve colour quality
•Burning position horizontal ± 45°
Environment
•Good environmental choice because of high
energy e ciency and long reliable life
•This product is RoHS compliant
•This product is covered by WEEE
Application
•Shops and shop windows, o ces and public
buildings
•Decorative outdoor: floodlighting of
facades, statues and monuments
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•Lamps may use electronic or electromag-
netic control gear
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
MASTERColour CDM-TD RX7s
Wattage/
Colour Code
Colour
Tempera-
ture
Lamp
Lumi-
nous Flux
EM
Life to 10%
failures
Life to 50%
failures
Burning
Position
Dim. no. Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8711500...
(K) (lm) (h) (h)
70W/830 3,000 6,000 13,000 16,000 p45 A+ 1 1CT / 12 12 70CDMTD830 197825 15 yes
70W/942 4,200 5,600 13,000 16,000 p45 A+ 2 1CT / 12 12 70CDMTD942 200020 15 yes
150W/830 3,000 13,250 13,000 16,000 p45 A+ 3 1CT / 12 12 150CDMTD830 197849 15 yes
150W/942 4,200 13,750 13,000 16,000 p45 A+ 3 1CT / 12 12 150CDMTD942 200259 15 yes
MASTERColour CDM-Rm Elite Mini
D
C1
C
A
A C C1 D
max. nom. max. nom.
59 62.75 60.9 50
Perfect sparkle, easy application
Mini, very high-e ciency Ceramic Metal
Halide discharge reflector lamp producing
crisp white sparkling light with high colour
rendering
Product Benefits
•High-intensity beam of crisp white sparkling
light makes merchandise look irresistible
•Easy to install and replace, reducing
installation and relamping costs
•Fits in small luminaires which are less visible
Product Features
•Crisp white sparkling light
•Excellent colour rendering, with extra red
•High e cacy with unparalleled lumen
maintenance
•Mini design fitting in open luminaires
•UV-blocking front glass
Environment
•Good environmental choice because of high
energy e ciency and long reliable life
•The product is certified by Philips Green
Flagship
•The product is RoHS compliant
•The product is covered by WEEE
Application
•Accent and display lighting in retail
•General and decorative indoor lighting
Warnings and Safety
•Use only with electronic control gear
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
