Lamps & Lighting Electronics Catalogue 2014

77 / 272

>
MASTERColour CDM-T Evolution
D
L
C
O
Dim. C D L O
no. max. max. nom. nom.
1 103 20 56 3.6
2 103 20 56 5.5
3 103 20 56 7.2
Ultimate sparkle, unbeatable value
Single-ended, highest-e ciency, longest-life
Ceramic Metal Halide discharge lamp
producing crisp white sparkling light with high
colour rendering
Product Benefits
•High-intensity beam of crisp white sparkling
light makes merchandise look irresistible
•Stable colour and lumen output over life
keeps your store attractive season after
season
•Lowest Total Cost of Ownership as a result
of high e cacy (same light, less energy or
same energy, more light) and long life
Product Features
•Crisp white sparkling light
•Excellent colour rendering, with extra red
•High e cacy with unrivalled lumen
maintenance
•Stable colour performance over lifetime
•Clean beam
Environment
•Excellent environmental choice because of
high energy e ciency and long reliable life
•Philips Green Flagship
•RoHS-compliant
•Covered by WEEE
Application
•Accent and display lighting in retail
•General and decorative indoor lighting
Warnings and Safety
•Use only in a totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•Use only with electronic control gear
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
•CDM Evolution lamps are designed to
comply with IEC standards
•The vast majority of drivers are fully
compatible with CDM Evolution lamps.
However, we are also aware that the use
of CDM Evolution lamps in combination
with certain type of drivers may cause
undesired performance issues and for that
reason we advise you to always perform a
driver compatibility check to ensure proper
operation.
MASTERColour CDM-T Evolution G12
Wattage/
Colour Code
Colour
Temperature
Lamp
Luminous Flux
EL
Burning
Position
Dim. no. Packing type/
Packing
configuration
National Order Code Ordering
number
8718291...
(K) (lm)
20W/930 3,000 2,050 any A+ 1 1CT / 12 12 20CDMTEVO930 659129 00 yes
35W/930 3,000 4,300 any A+ 2 1CT / 12 12 35CDMTEVO930 651215 00 yes
50W/930 3,000 5,700 vbu/vbd60 A+ 3 1CT / 12 12 50CDMTEVO930 701224 00 yes
Philips Lamps and Lighting Electronic Catalogue 2014 77
05
