MASTERColour CDM-T
Product Description
•Range of single-ended, compact, high-
e ciency, discharge lamps with a stable
colour over lifetime and a crisp, sparkling
light
Product Benefits
•Stable colour impression over lifetime
•High lamp e cacy results in low operating
costs and low heat generation
•Long lamp life compared with incandescent
and halogen lamps
•Relatively low heat output enhances comfort
for shoppers and sta
•All types are UV-Block for reduced fading
risks
Product Features
•Warm or cool white colour impression
•Colour rendering good to excellent
•Allows small-size luminaires designs that give
high beam intensities
Environment
•Good environmental choice because of high
energy e ciency and long reliable life
•This product is RoHS compliant
•This product is covered by WEEE
Application
•Shops and shop windows, o ces and public
buildings
•Decorative outdoor: floodlighting and
pedestrian areas
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
•Lamps may use electronic or electromag-
netic control gear, except 35 W/942 and
20 W lamps, which must use electronic
control gear.
D
L
C
O
Dim. C D L O
no. max. max. nom. nom.
1 103 20 56 4
D
L
C
O
Dim. C D L O
no. max. max. nom. nom.
2 103 20 56 5
3 103 20 56 7
4 103 20 56 6
5 110 20 56 9
6 110 20 56 8
D
L
C
O
Dim. C D L O
no. max. max. nom. nom.
7 135 25 72.5 12.3
MASTERColour CDM-T G12
Wattage/
Colour
Code
Colour
Tem-
perature
Lamp
Luminous
Flux EL
Lamp
Lumi-
nous
Flux
EM
Life to
10%
failures
EL
Life to
50%
failures
EL
Burning
Position
Dim.
no.
Packing
type/
Packing
configu-
ration
National
Order Code
Ordering number
(K) (lm) (lm) (h) (h)
20W/830 3,000 1,800 10,000 15,000 any A+ 1 1CT / 12 12 20CDMT830+ 872790087156200 yes
35W/830 3,000 3,150 3,000 9,000 12,000 any A+ 2 1CT / 12 12 35CDMT830 871150019697215 yes
35W/842 4,200 3,100 9,000 12,000 any A+ 2 1CT / 12 12 35CDMT942 871150021126215 yes
70W/830 3,000 6,500 6,400 10,000 12,000 any A+ 3 1CT / 12 12 70CDMT830 871150019699615 yes
70W/942 4,200 6,300 6,300 10,000 12,000 any A+ 4 1CT / 12 12 70CDMT942 871150019927015 yes
150W/830 3,000 13,600 13,200 10,000 12,000 any A+ 5 1CT / 12 12 150CDMT830 871150019780115 yes
150W/942 4,200 12,700 12,000 10,000 12,000 any A+ 6 1CT / 12 12 150CDMT942 871150020005115 yes
250W/830 3,000 27,540 4,500 8,000 any A+ 7 1CT / 12 12 250CDMT830 871150020801915 yes
250W/942 4,200 26,000 4,500 8,000 any A+ 7 1CT / 12 12 250CDMT942 871150021112515 yes
