Lamps & Lighting Electronics Catalogue 2014

82 / 272

>
O
L
C
D
Dim. C D L O
no. max. max. nom. nom.
1 85 15 52 4
O
L
C
D
Dim. C D L O
no. max. max. nom. nom.
2 85 15 52 5
O
L
C
D
Dim. C D L O
no. max. max. nom. nom.
3 85 15 52 7
O
L
C
D
Dim. C D L O
no. max. max. nom. nom.
4 85 15 52 5
MASTERColour CDM-TC G8.5
Wattage/
Colour
Code
Colour
Tem-
perature
Lamp
Luminous
Flux EL
Lamp
Lumi-
nous
Flux
EM
Life to
10%
failures
EL
Life to
50%
failures
EL
Burning
Position
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering number
(K) (lm) (lm) (h) (h)
20W/830 2,980 1,800 10,000 15,000 any A+ 1 1CT / 12 12 20CDMTC830+ 872790087158600 yes
35W/830 3,000 3,100 3,000 8,000 12,000 any A+ 2 1CT / 12 12 35CDMTC830 871150020000615 yes
35W/842 4,200 3,100 8,000 12,000 any A+ 2 1CT / 12 12 35CDMTC942 871150020957315 yes
70W/830 3,000 6,400 8,000 12,000 any A+ 3 1CT / 12 12 70CDMTC830 871150020167615 yes
70W/842 4,200 5,800 8,000 12,000 any A+ 4 1CT / 12 12 70CDMTC942 871150021275715 yes
MASTERColour CDM-T Fresh
Incredible colours, unbeatable e ciency
Single-ended, high-e ciency Ceramic Metal
Halide discharge lamp with special colour
enhancement properties
Product Benefit
•Makes fresh food (meat, fish, fruit, veget-
ables) look incredibly beautiful with full
colours
•Makes coloured packaging material look
vibrant
•Saves 30-50% energy compared to normal
SDW!
Product Feature
•Excellent colour enhancement (red, green,
orange, blue)
•Highest e cacy in fresh food lighting
•Long life with stable colour
•Standard CDM shapes and sizes
•Can be operated on standard CDM gear
Application
•Fresh food displays
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•Use only with electronic control gear
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
D
L
C
O
C D L O
max. max. nom. nom.
103 20 56 7.15
MASTERColour CDM-T Fresh G12
Wattage/
Colour Code
Colour
Tempera-
ture
Lamp
Luminous
Flux EL
Life to 10%
failures EL
Life to 50%
failures EL
Burning
Position
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8718291...
(K) (lm) (h) (h)
70W/740 4,000 6,000 10,000 15,000 any A+ 1CT / 12 12 70CDMTFRESH 12544000 yes
Philips Lamps and Lighting Electronic Catalogue 2014 82
