PL-Q 4 Pin
U C1 C
E
D
D1
F
Dim. C C1 D D1 E F U
no. max. max. max. max. max. max. max.
1 141 51 15 27.5 138 41 40
2 207 77 24 33.0 205 41 49
Product Description
•Compact fluorescent lamps with a
quadrant-like shape
Product Benefits
•High light quality and optimum lumen output
provide increased value for money
•Energy-saving light with good colour
rendering
•Long service lifetime
•The Philips Lighting stamp of quality
Product Features
•Retrofit in already installed 2D luminaires
•Assembled with the same high-quality
components as all other Philips CFL-NI
lamps
•Dimming is possible
Application
•Ideal for applications such as
-corridors
-toilets
-stairwells
-reception areas
Warnings and Safety
•Lamp light technical and electrical char-
acteristics are influenced by operating
conditions, i. e. lamp ambient temperature
and operating position as well as applied HF
control gear
•Shorter lamp life when often switching and
not well pre-heated electrodes
PL-Q /4P GR10q
Wattage/
Colour Code
Colour
Rendering
Index
Dimma-
ble
Life to 10%
fail Preheat
EL,3h
Life to 50%
fail Preheat
EL,3h
Dim. no. Packing type/
Packing
configuration
National Order
Code
Ordering
number
8711500...
(Ra) (h) (h)
16W/835 82 yes 8,000 13,000 A 1 1CT / 10 10 16PLQ8354PIN 27206525 yes
28W/827 82 yes 8,000 13,000 A 2 1CT / 10 10 28PLQ8274PIN 26991125 yes
28W/830 82 yes 8,000 13,000 A 2 1CT / 10 10 28PLQ8304PIN 26992825 yes
28W/835 82 yes 8,000 13,000 A 2 1CT / 10 10 28PLQ8354PIN 26967625 yes
28W/840 82 yes 8,000 13,000 A 2 1CT / 10 10 28PLQ8404PIN 26993525 yes
38W/830 82 yes 8,000 12,000 A 2 1CT / 10 10 38PLQ8304PIN 27172325 yes
38W/835 82 yes 8,000 13,000 A 2 1CT / 10 10 38PLQ8354PIN 27173025 yes
38W/840 82 yes 8,000 13,000 A 2 1CT / 10 10 38PLQ8404PIN 27174725 yes
