MASTER PL-L Polar 4 Pin
A
D D1
B C
Dim. A B C D D1
no. max. max. max. max. max.
1 385 410 416.6 39 18
2 510 535 541.6 39 18
Product Description
•Energy-saving compact fluorescent lamps
•Compact long-arc low-pressure mercury
discharge lamp
•Envelope consists of 2 parallel fluorescent
tubes linked by a bridge
•4-pin base without gear
Product Benefits
•Road and social safety are safeguarded even
at freezing outdoor temperatures
•Lowest cost of ownership thanks to a
service lifetime of over 16,000 hours
•Environmental impact minimised by long
lifetime and low hazardous materials content
•Dimming is possible
Product Features
•Bridge between tubes adapted to maximise
light output at low ambient temperatures
•Optimum light output achieved in outdoor
and cold storage applications
•Lumen maintenance of 90% and and long
service lifetime
•Lamp characteristics are influenced by
operating conditions and control gear used
Environment
•Good environmental choice because of
high energy e ciency, long life and low light
output depreciation, lowest mercury content
•Compliant with all RoHS and WEEE require-
ments: the lamps have a very low content of
mercury, are lead free and make no use of
radioactive materials and hazardous flame
retardants
Application
•Residential areas
•Parks and squares
•Under canopies in storage and transport
areas
•Cold indoor areas (e. g. warehouses, food
cold stores)
Warnings and Safety
•Lamp light technical and electrical char-
acteristics are influenced by operating
conditions, i. e. lamp ambient temperature
and operating position as well as applied
control gear
•Shorter lamp life when often switching and
not well pre-heated electrodes
MASTER PL-L Polar /4P 2G11
Wattage/
Colour Code
Colour
Rendering
Index
Luminous
Flux EL
25°C, Rated
Dimma-
ble
Life to 10%
fail Preheat
EL,3h
Life to 50%
fail Preheat
EL,3h
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8711500...
(Ra) (lm) (h) (h)
36W/830 82 2,900 yes 14,000 20,000 A 1 1CT / 25 25 36PLL830POLAR 26158840 yes
36W/840 82 2,900 yes 14,000 20,000 A 1 1CT / 25 25 36PLL840POLAR 26160140 yes
55W/840 82 4,800 yes 14,000 20,000 A 2 1CT / 25 25 55PLL840POLAR 26164940 yes
