MASTER PL-T Xtra 4 Pin
Product Description
•Energy saving compact fluorescent lamp
•Compact long-arc low-pressure mercury
discharge lamp
•Envelope consists of 6 parallel narrow
fluorescent tubes
Product Benefits
•Extra long life
•Longer lifetime and less early failures lead
to less hassle and lower maintenance costs
and facilitate the change from spot to group
replacement
•Optimal light performance for long
operation per switch on
•More light (about 15% more) per light point
than common
Product Features
•4-pin base without glow switch starter and
capacitor
•Fast light run up under all circumstances
•Philips invented bridge technology applied
•Significant reduction of early failures
•Extra long and reliable lifetime
Environment
•Good environmental choice because of long
reliable life, high-energy e ciency and lowest
mercury content
•Compliant with all RoHS and WEEE
requirements: lamps contain very low level
of mercury, are lead free and make no use
of radioactive materials and hazardous flame
retardants
Application
•Designed for general or supplementary
lighting in professional and semi-professional
environments
•Ideal for use in recessed or surface mounted
downlighters, wall units, outdoor lighting
•Suitable for use in applications where
maintenance costs are high (high ceilings,
di cult to reach): department stores,
supermarkets, warehouses, production halls
and public areas
Warnings and Safety
•Lamp light technical and electrical char-
acteristics are influenced by operating
conditions, i. e. lamp ambient temperature
and operating position as well as applied HF
control gear
•Shorter lamp life when often switching and
not well pre-heated electrodes
A
D
B
C
Dim. A B C D
no. max. max. max. max.
1 98.7 123 138.7 41
A
D
B
C
Dim. A B C D
no. max. max. max. max.
2 120.7 145 160.7 41
A
D
B
C
Dim. A B C D
no. max. max. max. max.
3 157.7 182 197.7 41
MASTER PL-T Xtra /4P
Wattage/
Colour
Code
Cap-Base Colour
Rende-
ring
Index
Luminous
Flux EL
25°C,
Rated
Dim-
mable
Life to
10% fail
Preheat
EL,3h
Life to
50% fail
Preheat
EL,3h
Dim.
no.
Packing type/
Packing
configuration
National Order
Code
Ordering
number
8711500...
(Ra) (lm) (h) (h)
32W/830 GX24q-3 82 2,400 yes 20,000 33,000 A 1 1CT / 5X10CC 50 32PLT8304PXTRA 897404 70 yes
32W/840 GX24q-3 82 2,400 yes 20,000 33,000 A 1 1CT / 5X10CC 50 32PLT8404PXTRA 897435 70 yes
42W/830 GX24q-4 82 3,050 yes 20,000 33,000 A 2 1CT / 5X10CC 50 42PLT8304PXTRA 897466 70 yes
42W/840 GX24q-4 82 3,050 yes 20,000 33,000 A 2 1CT / 5X10CC 50 42PLT8404PXTRA 897497 70 yes
57W/840 GX24q-5 82 4,200 yes 20,000 33,000 A 3 1CT / 5X10CC 50 57PLT8404PXTRA 897558 70 yes
