MASTER PL-T 2 Pin
Product Description
•Energy saving compact fluorescent lamp
•Compact long-arc low-pressure mercury
discharge lamp
•Envelope consists of 6 parallel narrow
fluorescent tubes
Product Benefits
•Optimal light performance for short or long
operation per switch on
•Substantial more light (about 15% more) per
light point than common
•Long life and sustainable light output
Product Features
•2-pin base with a housing incorporating the
lamp glow switch starter
•Fast light run up
•Philips invented bridge technology applied
•Dimming is not possible
Environment
•Good environmental choice because of
high energy e ciency, long life and low light
output depreciation, lowest mercury content
•Compliant with all RoHS and WEEE require-
ments: the lamps have a very low content of
mercury, are lead free and make no use of
radioactive materials and hazardous flame
retardants
Application
•Designed for general or supplementary
lighting in professional and semi-professional
environments
•Ideal for use in recessed or surface mounted
downlighters, wall units
Warnings and Safety
•Use only with electromagnetic control gear
•Lamp light technical and electrical char-
acteristics are influenced by operating
conditions, i. e. lamp ambient temperature
and operating position
•Dimming is not possible
A
D
B
C
Dim. A B C D
no. max. max. max. max.
1 71.8 96 119.2 41
A
D
B
C
Dim. A B C D
no. max. max. max. max.
2 86.7 111 134.2 41
MASTER PL-T /2P
Wattage/
Colour
Code
Cap-Base Colour
Rende-
ring
Index
Luminous
Flux EM
25°C,
Rated
Dim-
mable
Life to
10%
failures
EM
Life to
50%
failures
EM
Dim.
no.
Packing type/
Packing
configuration
National Order
Code
Ordering
number
8711500...
(Ra) (lm) (h) (h)
18W/840 GX24d-2 82 1,200 no 6,500 10,000 B 1 1CT / 5X10CC 50 18PLT8402PINCS 61061470 yes
26W/830 GX24d-3 82 1,725 no 6,500 10,000 B 2 1CT / 5X10CC 50 26PLT8302PINCS 61102470 yes
26W/840 GX24d-3 82 1,725 no 6,500 10,000 B 2 1CT / 5X10CC 50 26PLT8402PINCS 61113070 yes
