Lamps & Lighting Electronics Catalogue 2014

96 / 272

>
MHN-TD
O
D
L
B
C
Dim. B C D L O
no. max. max. max. nom. nom.
1 114.2 117.6 19.5 57 7.7
2 132.0 135.4 23.0 66 17.8
Product Description
•Double-envelope, single- or double-ended
Metal halide lamps
Product Benefits
•All types are UV-Block for reduced health
and fading risks
Product Features
•Quartz discharge tube containing high-
pressure mercury and a mixture of
dysprosium, holmium and thulium halides
(MHN-TD) or tin iodide (MHW-TD),
with sodium and thallium added for colour
correction and arc stabilisation
•Double-ended lamps housed in a tubular
clear UV-Block quartz evacuated outer
envelope
•Restricted burning position
Application
•Indoors - accent lighting, general lighting in
downlighters, e. g. in shops and malls
•Downlighters, uplighters and wall-washers,
e. g. in shops and malls
•Outdoors - floodlighting monuments,
facades and billboards
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
MHN-TD RX7s
Wattage/
Colour Code
Colour
Tempera-
ture
Lamp
Lumi-
nous
Flux EM
Life to
10%
failures
Life to
50%
failures
Burning
Position
Dim.
no.
Packing
type/
Packing
configu-
ration
National
Order Code
Ordering number
(K) (lm) (h) (h)
70W/730 3,000 6,000 9,000 p45 A+ 1 1CT / 12 12 70MHWTD 871829121530100 yes
70W/730 3,000 6,200 6,000 9,000 p45 1 1CT / 12 12 70MHWTD 871150056268515 yes
150W/730 3,000 13,800 6,500 10,500 p45 2 1CT / 12 12 150MHWTD 871150019350615 yes
150W/842 4,200 12,900 10,500 p45 A+ 2 1CT / 12 12 150MHNTD 871829121536300 yes
Philips Lamps and Lighting Electronic Catalogue 2014 96
05
