Lamps & Lighting Electronics Catalogue 2014

207 / 272

>
A2
A1
B1
C1
B2
D1
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
1 132 122.4 34.2 24.6 25 4.5
Dim. A1 A2 B1 B2 C1
no. nom. nom. nom. nom. nom.
2 240 225 43.2 30 29.5
A2
A1
B1
C1
B2
D1
Dim. A1 A2 B1 B2 C1 D1
no. nom. nom. nom. nom. nom. nom.
3 88.9 76 83 70 38 3.8
Type Input Voltage
Range (AC)
Input Frequency Dim. no. Packing type/
Packing
configuration
National Order Code Ordering
number
8711500...
(V) (Hz)
LED Driver Outdoor 12W/0.35A-33V 230V 50 1 1NO / 10 10 XTMSELV0.35A12W 930453 30
LED Driver Outdoor 67W/2.80A-24V 230V 50 2 1NO / 20 20 XTMSELV2.80A67W 931207 30
LED Driver Outdoor 40W/1.75A-24V 230V 207-264 50 3 1NO / 12 12 XTMSELV1.75A40W 912732 30
Xitanium Constant Current Xtreme
A3
D1
X1 X1
Dim. A1 A2 A3 B1 B2 C1 D1 X1
no. nom. nom. nom. nom. nom. nom. nom. nom.
1 240.5 226.2 211.1 59.1 42.9 37.1 8 280
2 240.5 226.2 211.1 59.1 42.9 37.1 8 500
Breakthrough in performance, flexibility
and reliability
Xitanium Xtreme LED drivers provide
constant current output, optimal for a single
string of LEDs. With exceptional operating
e ciency, our drivers significantly reduce
energy costs. The Xitanium Xtreme portfolio
o ers both central and standalone dimming
protocols further increasing the energy
savings and CO2 reductions achieved with
LED lighting. The fully programmable drivers
deliver all dimming options and a range of
currents in a single driver. System reliability
is maximized with intelligent temperature
monitoring of the LED light engine. The full
portfolio o ers maximum flexibility with
customizable operating settings, delivering
optimal performance tailored for each design.
Product Benefits
•Design flexibility - one driver can be
programmed for many di erent luminaire
designs
•Improved logistics and stock management
•Peace of mind on product performance
Product Features
•Xtreme standard: Long lifetime, robust
protection against moisture, vibration and
temperature extremes
•Module temperature protection
•Adjustable output current
•Constant Light Output
•Multiple dimming protocols
Application
•Urban street lighting
•Functional road & tunnel lighting
•Area and flood illumination
Type Input Voltage
Range (AC)
Input Frequency Dim. no. Packing type/
Packing
configuration
National Order Code Ordering
number
8727900...
(V) (Hz)
Xitanium 150W 0.70A 230V sXt 220-240 50/60 1 UNP / 10 10 XTM0.70A150W 809176 00
Xitanium 150W 0.35-0.7A GL Prog sXt 120-277 50/60 2 UNP / 10 10 XIT150WPROG 783513 00
