OccuSwitch
OccuSwitch - a smart move
The OccuSwitch is a movement detector with
a built-in switch. It will switch the lights o in a
room or area when it is vacated and thus save
up to 30% on electricity
The OccuSwitch can switch any load of up to
6 A and control an area of between 20 and 25
m2.
A detachable mains connector enables easy
installation and mounting of the OccuSwitch
in the ceiling, a separate Wieland cable
is available for easy, fast and trouble-free
installation
Benefits
•Energy savings of up to 30% and good
pay-back
•Works with almost all lamp- and luminaire
types
•Easy to install, enables even faster installation
by optional Wieland connectors.
Features
•OccuSwitch has a smart timer that will
extend the delay time by 10 minutes if move-
ment is detected shortly after switch-o ,
assuming that the area is still in use but there
is very little movement
•The OccuSwitch has a retractable shield
that can be used to shield o areas, e.
g. corridors, adjacent to the area the
OccuSwitch is controlling
Application
•The OccuSwitch is designed for use in
o ces, schools and similar applications,
including toilets, storage rooms, etc
•It is optimised for recessed ceiling mounting
and for mounting heights between 2.5 and 4
metres
•The surface box also enables surface
mounting, with either recessed wiring or
surface-mounted ducts
67.5
500
113.5
26.5
Dim. no. 1
51.5
95
Dim. no. 2
45
122
Dim. no. 3
80
60
66
Dim. no. 4
80 55
80
Dim. no. 5
86
86
46.5
Dim. no. 6
72
88
106
Dim. no. 7
Ø 80
Ø 95
50
Dim. no. 8
Type Dim. no. Packing type/Packing
configuration
Ordering number
LCC1070/00 PIR T-CABLE 3P 1 1CT / 20 20 871155973177399
LRH1070/00 SENSR SURFACE 2 1CT / 42 42 871155973143899
LRM1000 OS mov det 3 1CT / 48 63 871829122557700
LRM1010 OS mov det small 4 1CT / 75 80 871829122561400
LRM1020 OS mov det corridor 5 1CT / 75 120 871829122563800
LRM1030 OS mov det switch 3 wire 6 1CT / 75 30 871829122565200
LRM1040 OS mov det IP55 240dgr 7 1CT / 32 36 871829122573700
LRM1070/00 SENSR MOV DET ST 8 1CT / 42 42 871155973138499
LRM1080/00 SENSR MOV DET ST IR 8 1CT / 42 42 871155973140799
