OccuSwitch DALI
Ø 95 mm
60 mm
40 mm
60 mm
52 mm
2 inch
OccuSwitch DALI – a simple solution for
demanding installations
OccuSwitch DALI is a combined sensor
and controller and will dim and switch the
lights in a room or area upon occupancy
and according to the available daylight, with
options for local override, parallel operation
and network links to Building Management
Systems (BMS).
Can control up to 15 DALI luminaires and is
easy to install, requires limited commissioning,
if any. With optional extension sensor(s)
(LRM8118) and push-button interface(s)
(LCU2070).
Separate Wieland cables available for easy,
fast and trouble-free installation.
Benefits
•Energy savings of up to 55% and good TCO
•Adds comfort with local control
•Easy to use (works right out of the box) but
also easy to adapt to specific applications or
user demands
Features
•Advanced occupancy control and daylight
regulation with separate window and
corridor algorithms
•Retractable shield that can be used to shield
o areas, e. g. corridors, adjacent to the
area the OccuSwitch DALI is controlling
•Push-button interface for the use of
standard wired switches
•Energy indicator shows relative energy usage
•BMS version interacts with almost any
building management system via the DALI
interface
Application
•OccuSwitch DALI is designed for use in
o ces, schools (incl. board lighting) and
similar applications, including small meeting
rooms, lobbies and corridors
•It is optimised for recessed ceiling mounting
and for mounting heights of between 2.5 and
4 metres
•The surface box also allows surface
mounting, with either recessed wiring or
surface-mounted ducts
Type Packing type/Packing configuration Ordering number
LCC2070/00 CABLE BASIC 1BG / 18 18 871155973248099
LCC2080/00 CABLE ADV + BMS 1BG / 18 18 871155973250399
LCU2070/00 PBU 1BG / 50 50 872790087026800
LRH2070/00 SURFACE BOX 1CT / 42 42 871155973252799
LRM2070 BASIC 1CT / 42 42 871155973230599
LRM2080 ADVANCED 1CT / 42 42 871155973234399
