OccuSwitch Wireless
A wide range of wireless sensors with
movement detection to control an area of
20-25 m2. Battery-operated, with a typical
lifetime of 8-10 years. The actuator can switch
any load up to 6 A and can be located in the
ceiling or corridor. OccuSwitch Wireless
will switch the lights o in a room or area
when it is vacated and so save up to 30%
on electricity. A detachable mains wiring
connector enables easy installation. Separate
Wieland and CEE cables are available for even
easier, faster and trouble-free installation.
Up to 10 sensors and/or actuators can be
combined in one parallel network. The
maximum distance between the sensor and
actuator is 10 meters (depending on the
application). With the extended scope of
OccuSwitch Wireless functionality (increased
number of sensors and interoperable
with wireless ActiLume range), all wireless
devices should be from the same version
(LRM/LRA/LLC XXXX/10 or higher).
Benefits
•Energy savings of up to 30%. Additional
savings can be obtained in combination with
ActiLume Wireless.
•O ers an easy-to-apply solution, especially
for existing non-electronic (EM) lighting
systems.
•Wireless sensor can be mounted in various
places and o ers maximum flexibility. The
actuator is designed for any wiring system.
Features
•Smart timer extends the delay time by
5% if movement is detected shortly after
switch-o , assuming that the area is still in
use but there is very little movement.
•The ceiling sensor has a retractable shield
that can be used to shield o areas, e. g.
corridors adjacent to the area in which
OccuSwitch Wireless is operating.
•There is considerable freedom in terms of
where to mount the OccuSwitch Wireless
actuator to minimize installation cost and
time.
Application
•OccuSwitch Wireless is designed for use
in open-plan o ces, schools and similar
applications, including toilets, storage rooms,
etc.
•The ceiling sensor is optimised for mounting
heights between 2.5 and 4 metres, the
corridor, corner and wall sensors for heights
between 2.1 and 2.5 metres
STELVIO plug:
MRT3 P 5,08/6 VE
500
GST18i3
female
GST18i3
male
L
L
N
N
Dim. no. 1 Dim. no. 2 Dim. no. 3 Dim. no. 4
Type Dim. no. Packing type/Packing
configuration
Ordering number
LCC1720/00 WIELAND CABLE 1 1BG / 15 15 872790091400900
LRM1765/10 OS Wireless Corridor sensor 2 1CT / 20 20 871829125065400
LRM1770/10 OS Wireless Corner sensor 3 1CT / 20 20 871829125061600
LRM1775/10 OS Wireless Wall sensor 4 1CT / 20 20 871829125063000
