www.furse.comESP PCB/E Series
Technical specification
1
Nominal voltage (DC or AC peak) measured at < 10 µA
(ESP PCB/15E, ESP PCB/30E, ESP PCB/50E, ESP PCB/110E) and
< 200 µA (ESP PCB/06E).
2
Maximum working voltage (DC or AC peak) measured at
< 5 mA leakage (ESP PCB/15E, ESP PCB/30E, ESP PCB/50E,
ESP PCB/110E), < 10 mA (ESP PCB/06E).
3
The maximum transient voltage let-through of the protector
throughout the test (±10%), line to line & line to earth, both
polarities. Response time < 10 ns.
4
Test to IEC 61000-4-5:2006, ITU-T (formerly CCITT) K.20,
K.21 and K.45,Telcordia GR-1089-CORE, Issue 2:2002,
ANSI TIA/EIA/IS-968-A:2002 (formerly FCC Part 68).
5
The installation and connections external to the protector
may limit the capability of the protector.
30 mm
(~1 1/2”)
22.86 mm
(0.9”)
1
2
4 3
5.08 mm
(0.2”)
5.08 mm
(0.2”)
5.08 mm
(0.2”)
Depth: 20 mm (~0.8”)
Weight: 35 g
Pins are positioned centrally
Pin 1 connects through Pin 3
Pin 2 connects through Pin 4
(Underside pin view)
30 mm
(~1 1/2”)
Electrical specification
ESP PCB/06E
ESP PCB/15E
ESP PCB/30E
ESP PCB/50E
ESP PCB/110E
Nominal voltage
1
6 V
15 V
30 V
50 V
110 V
Maximum working voltage
U
c
2
7.79 V
16.7 V
36.7 V
56.7 V
132 V
Current rating
(signal)
1.25 A
In-line resistance
(per line ±10%)
1.0
Ω
Bandwidth
(-3 dB 50
Ω
system)
45 MHz
Transient specification
ESP PCB/06E
ESP PCB/15E
ESP PCB/30E
ESP PCB/50E
ESP PCB/110E
Let-through voltage
(all conductors)
3
U
p
C2 test 4 kV 1.2/50 µs, 2 kA 8/20 µs to
BS EN/EN/IEC 61643-21
36.0 V
39.0 V
60.0 V
86.0 V
180 V
C1 test 1 kV, 1.2/50 µs, 0.5 kA 8/20 µs to
BS EN/EN/IEC 61643-21
26.2 V
28.0 V
49.0 V
73.5 V
170 V
B2 test 4 kV 10/700 µs to BS EN/EN/IEC 61643-21
16.0 V
25.5 V
43.5 V
65.0 V
160 V
5 kV, 10/700 µs
4
17.0 V
26.2 V
44.3 V
65.8 V
165 V
Maximum surge current
5
D1 test 10/350 µs to
- per signal wire
BS EN/EN/IEC 61643-21
- per pair
2.5 kA
5 kA
8/20 µs to ITU-T K.45:2003, - per signal wire
IEEE C62.41.2:2002
- per pair
10 kA
20 kA
Mechanical specification
ESP PCB/E Series
Temperature range
-40 to +80 ˚C
Connection type
0.64 mm (0.025”) square PCB pins, 1.2 mm diameter PCB holes recommended
Case material
ABS UL94 V-0
Dimensions
