Offset type lug
A
B
C
D
E
F
Part
mm mm mm mm mm mm
No.
20
3
40
10
8.5
40
LO101
25
3
45
12
8.5
40
LO102-FU
25
3
45
12
10.5
40
LO103-FU
31
6
50
15
10.5
40
LO104
31
6
50
16
12.5
40
LO105
38
5
55
18
10.5
40
LO106
38
6
55
18
10.5
40
LO107
38
6
55
20
12.5
40
LO108
50
6
75
25
10.5
60
LO109
50
6
75
25
12.5
60
LO110
For suitable FurseWELD connection see page 135.
