TSC-0912 - 09.10.12
A
D
E
B
C
A
B
C
D
E
Part
mm
mm
mm
mm
mm
No.
20
3
45
10
8.5
LS101-FU
25
3
50
12
8.5
LS102-FU
25
3
50
12
10.5
LS103-FU
31
6
75
15
10.5
LS104-FU
31
6
75
15
12.5
LS105-FU
38
5
75
18
10.5
LS106-FU
38
6
75
18
10.5
LS107-FU
38
6
75
20
12.5
LS108-FU
50
6
95
25
10.5
LS109-FU
50
6
95
25
12.5
LS110-FU
Straight type lug
A
B
C
D
E
F
G
Part
mm mm mm mm mm mm mm
No.
20
3
40
10
8.5
40
10
LC101-FU
25
3
45
12
8.5
40
10
LC102-FU
25
3
45
12
10.5
40
10
LC103-FU
31
6
50
15
10.5
40
15
LC104-FU
31
6
50
16
12.5
40
15
LC105-FU
38
5
55
18
10.5
40
15
LC106-FU
38
6
55
18
10.5
40
15
LC107-FU
38
6
55
20
12.5
40
15
LC108-FU
50
6
75
25
10.5
60
20
LC109-FU
50
6
75
25
12.5
60
20
LC110-FU
Cranked type lug
A
D
E
B
C
F
45°
G
For suitable FurseWELD connection see page 135.
For suitable FurseWELD connection see page 135.
