www.emergi-lite.co.ukEMEX Mini
EMEX Power
| System design
Features and benefits
l
True AC/AC 50Hz output
l
1.5kVA rating with 525W for 3 hours, 700W for 2 hours and 1200W for
1 hour
l
Ability to use standard proprietary AC distribution and protection
devices on outgoing circuits
l
Compatibility with addressable test package using EMEX technology
l
Excellent overload capability in full emergency mode
l
Excellent recharge capability: 80% after 12-14 hours following
rated discharge
l
MCB protection throughout – no fuses
l
Individual MCB protection – AC and DC circuits
l
Cooling with on-demand operation (not continuously running)
l
Integral maintenance bypass facility (ability to support output load in
bypass mode whilst maintenance is performed)
l
Maintained output as standard (switchable to non-maintained)
l
IP21 rate cabinet as standard
l
Easy front panel access
l
Simple installation
Space saving and high performance
Part No
ELD8000.015
Description
Static Inverter EMEX Mini 1.5kVA
1-3H SPN
Mains supply
Voltage
230V to UK standards
Frequency
50/60Hz
Phase
1 phase
Current
10A Max
Output (Mains Healthy)
Voltage
230V (as supply)
Power
1500VA
Phase
1
Inverter output
Voltage
230V
Frequency
50/60Hz
Duration
1, 2 or 3 hour(s)
THD
< 5%
Waveform
Sinusoidal
Power factor range
0.9 lead to 0.7 lag
Phase
1
Inverter nominal rating
VA
1,500 VA
Wattage
1200W 1 hour
Wattage
700W 2 hours
Wattage
525W 3 hours
Battery
Ampere hour
24 Ah
Type
Valve regulated lead acid (VRLA)
Physical dimensions
Input terminals
2.5mm
Output terminals
2.5mm
Auxiliary terminals
2.5mm
Cabinet
610mm wide x 240mm deep x
1210mm tall
Weight
(Including battery)
166kg
Top entry gland plate
LED indications
Mains healthy
Supply from battery (mains failure or fault)
Meters
Non-optional extra
EMEX Mini specification
1210mm
240mm
610mm
