System components
EMEX Test | System components
Lamp Test Controller addressable interfaces
The LTC is designed specifically to control luminaires with fluorescent or incandescent lamps when working from a
static inverter system.
The LTC is part of the EMEX MXC automatic emergency lighting testing system, and can control the lamp and
dimmer signal when testing. It measures the lamp power consumption and communicates this and the lamp status
back to the EMEX central PC using power line communication via the MXC substation. It is fully addressable and
programmable for any lamp type or configuration. This is done in situ from the central PC.
70W LTC addressable interface
The LTC addressable interface unit is required when connecting standard
mains luminaires to the MXC substation system.
l Maximum 270V AC
l 70 watt maximum switching output power
l 2 control inputs configurable as local switched and unswitched
monitoring
l Factory pre-addressed
l 116.5mm x 24.5mm x 22mm
l Complies with Radiated & Conducted Emissions Standard EN55015:2000
230W DIM LTC addressable interface
l Maximum 270V AC
l 230 watt maximum switching output power
l 2 control inputs configurable as local switched and unswitched
monitoring
l Dim Relay to disconnect dimming signal
l Factory pre-addressed
l 155 x 42 x 30, 148mm fixing centres
l Complies with Radiated & Conducted Emissions Standard EN55015:2000
Lon Adapter
The LON adaptor interface allows integrators of Open System Networks
to provide network connectivity to Thomas & Betts Emergilite emergency
lighting systems.
The unit is housed in an industry-standard M36 DIN rail enclosure and
supports both RS232 and 11S4-65 communication options.
Simple ASCII string generated by the Emergilite system over RS232 is made
available through the open LonTalk protocol using Standard Network
Variable Type SNVT_str_ascii.
Note: The output format will be dependent on the Building Management
integrators system functionality and capabilities, see EMEX LONWorks
profile document for further information.
