Adaptaflex Product Catalogue |
LIT211GB 0715
2
Type A
Straight Fitting
Type B
Straight Fitting
Non-metallic conduit systems
Type A & B - Hi-Spec
IP Rating
Appropriate Conduit
For use with:
Hi-Spec Type PKTC / PKSS / PRTC / PRSS
IP40
N/A
IP65
N/A
IP66
Yes
IP67
Yes
IP68
N/A
IP69K
N/A
Type A - Hi-Spec
Straight Fitting - Fixed External Male Thread
/
For insertion into knockouts using a locknut
Materials:
Nickel Plated Brass
Nominal
Metric
Part No.
Conduit Size Thread
PBF13/M16/A
13mm
M16
PBF16/M16/A 16mm
M16
PBF21/M20/A 21mm
M20
PBC28/M25/A 28mm
M25
PBC34/M32/A 34mm
M32
PBC42/M40/A
42mm
M40
Temperature Range
Static Applications: -60ºC to +260ºC
Moving Applications: -45ºC to +260ºC
Fire Performance & EMI Screen
Approvals
Type B - Hi-Spec
Straight Fitting - Swivel External Male Thread
/
For insertion into threaded entries & knockouts
Materials:
Nickel Plated Brass
Nominal
Metric
Part No.
Conduit Size Thread
PBF13/M16/B 13mm
M16
PBF16/M16/B 16mm
M16
PBF21/M20/B 21mm
M20
PBC28/M25/B 28mm
M25
PBC34/M32/B 34mm
M32
PBC40/M40/B 42mm
M40
PBC54/M50/B
54mm
M50
Approvals
Temperature Range
Static Applications: -60ºC to +260ºC
Moving Applications: -45ºC to +260ºC
Fire Performance & EMI Screen
IP Rating
Appropriate Conduit
For use with:
Hi-Spec Type PKTC / PKSS / PRTC / PRSS
IP40
N/A
IP65
N/A
IP66
Yes
IP67
Yes
IP68
N/A
IP69K
N/A
