Non-metallic conduit systems
Accessories - Type T, Hinged ‘T’ Piece
Type T
Hinged ‘T’ Piece
/
Materials:
Polyamide (Nylon) 66 /
Colour:
Black (BL), Grey (GR)
Nominal Dimensions / Conduit Size
Part No.
A
B
C
D
E
T101010/BL 45.2mm
31.1mm
10mm
10mm
10mm
T101310/BL 45.2mm
31.1mm
10mm
13mm
10mm
T101613/BL 45.2mm
31.1mm
10mm
16mm
13mm
T131010/BL 45.2mm
31.1mm
13mm
10mm
10mm
T131013/BL 45.2mm
31.1mm
13mm
10mm
13mm
T131310/BL 45.2mm
31.1mm
13mm
13mm
10mm
T131313/BL 45.2mm
31.1mm
13mm
13mm
13mm
T131613/BL 45.2mm
31.1mm
13mm
16mm
13mm
T161013/BL 49.1mm
34.8mm
16mm
10mm
13mm
T161313/BL 49.1mm
34.8mm
16mm
13mm
13mm
T161316/BL 49.1mm
34.8mm
16mm
13mm
16mm
T161613/BL 49.1mm
34.8mm
16mm
16mm
13mm
T161616/BL 49.1mm
34.8mm
16mm
16mm
16mm
T162113/BL 49.1mm
34.8mm
16mm
21mm
13mm
T162116/BL 49.1mm
34.8mm
16mm
21mm
16mm
T211016/BL 56.5mm
41.0mm
21mm
10mm
16mm
T211021/BL 56.5mm
41.0mm
21mm
10mm
21mm
T211316/BL 56.5mm
41.0mm
21mm
13mm
16mm
T211321/BL 56.5mm
41.0mm
21mm
13mm
21mm
T211613/BL 56.5mm
41.0mm
21mm
16mm
13mm
T211616/BL 56.5mm
41.0mm
21mm
16mm
16mm
T211621/BL 56.5mm
41.0mm
21mm
16mm
21mm
T212113/BL 56.5mm
41.0mm
21mm
21mm
13mm
T212116/BL 56.5mm
41.0mm
21mm
21mm
16mm
T212121/BL 56.5mm
41.0mm
21mm
21mm
21mm
T281021/BL 64.5mm
48.5mm
28mm
10mm
21mm
T281028/BL 64.5mm
48.6mm
28mm
10mm
28mm
T281321/BL 64.5mm
48.6mm
28mm
13mm
21mm
T281328/BL 64.5mm
48.6mm
28mm
13mm
28mm
T281621/BL 64.5mm
48.6mm
28mm
16mm
21mm
T281628/BL 64.5mm
48.6mm
28mm
16mm
28mm
T282121/BL 64.5mm
48.6mm
28mm
21mm
21mm
T282128/BL 64.5mm
48.6mm
28mm
21mm
28mm
T282828/BL 64.5mm
48.6mm
28mm
28mm
28mm
T341634/BL 72.0mm
55.3mm
34mm
16mm
34mm
T342128/BL 72.0mm
55.3mm
34mm
21mm
28mm
T342134/BL 72.0mm
55.3mm
34mm
21mm
34mm
T343434/BL 72.0mm
55.3mm
34mm
34mm
34mm
Type PA
Hinged ‘T’ Piece
Temperature Range
Static Applications: -40ºC to +120ºC
Moving Applications: -5ºC to +120ºC
Fitting Characterstics
Snap Fit
Approvals
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / PR / PF
IP40
Yes
IP65
N/A
IP66
N/A
IP67
N/A
IP68
N/A
IP69K
N/A
B
C
A
D
E
10T
13T
16T
21T
28T
34T
