Non-metallic conduit systems
Type PRTC & PRSS - Hi-Spec
Type PRTC - Hi-Spec
High Specification, High EMI Screening Conduit
Materials:
PA (Nylon) 6 Conduit, Tinned Copper overbraid
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PRFSTC16
16mm
13
Fine
17.2mm
11.7mm
35mm
50m
PRFSTC21
21mm
17
Fine
23.6mm
16.6mm
45mm
50m
PRCSTC28
28mm
23
Coarse
30.0mm
21.7mm
50mm
50m
PRCSTC34
34mm
29
Coarse
36.0mm
27.7mm
60mm
50m
PRCSTC42
42mm
36
Coarse
43.5mm
35.1mm
65mm
25m
PRCSTC54
54mm
48
Coarse
56.5mm
46.6mm
75mm
25m
To order quote part number, colour & reel length, e.g. PAFL13/BL/50M
Temperature Range
Static Applications: -40ºC to +120ºC
Moving Applications: -5ºC to +120ºC
Flexibility & Fatigue Life
High Flexibility - Medium Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
Approvals
Type PRTC
High Specification,
High EMI Screening Conduit
Type PRSS - Hi-Spec
High Specification, Standard EMI Screening Conduit
Materials:
PA (Nylon) 6 Conduit, Stainless Steel Overbraid
Nominal
NW
Conduit
Outside
Inside
Min. Bend
Reel
Part No.
Conduit Size Conduit Size Pitch
Diameter
Diameter
Radius
Length
PRFSSS16
16mm
13
Fine
17.2mm
11.7mm
35mm
50m
PRFSSS21
21mm
17
Fine
23.6mm
16.6mm
45mm
50m
PRCSSS28
28mm
23
Coarse
30.0mm
21.7mm
50mm
50m
PRCSSS34
34mm
29
Coarse
36.0mm
27.7mm
60mm
50m
PRCSSS42
42mm
36
Coarse
43.5mm
35.1mm
65mm
25m
PRCSSS54
54mm
48
Coarse
56.5mm
46.6mm
75mm
25m
To order quote part number, colour & reel length, e.g. PRFSTC21/50M
Approvals
Type PRSS
High Specification,
Standard EMI Screening Conduit
Temperature Range
Static Applications: -40ºC to +120ºC
Moving Applications: -5ºC to +120ºC
Flexibility & Fatigue Life
High Flexibility - Medium Fatigue Life
Fire Performance & EMI Screen
Self Extinguishing
UV Resistance
Very High
IP Rating
Appropriate Fitting
For use with:
Hi-Spec Type A & B
IP40
N/A
IP65
N/A
IP66
