Non-metallic conduit systems
Type T - Adaptalok ATS
™
Type T - Adaptalok ATS
™
3 Way ‘T’ Piece
/
Materials:
Polyamide (Nylon) 66 /
Colour:
Black (BL), Grey (GR) / Yellow (Y), Blue (B) Elastomer
Nominal Dimensions / Conduit Size
Part No.
A
B
C
D
E
AT211316/T 82mm
129mm
21mm
16mm
13mm
AT211321/T 82mm
122mm
21mm
21mm
13mm
AT211613/T 83mm
129mm
21mm
13mm
16mm
AT211616/T 83mm
129mm
21mm
16mm
16mm
AT211621/T 83mm
122mm
21mm
21mm
16mm
AT212113/T 75mm
129mm
21mm
21mm
13mm
AT211616/T 83mm
129mm
21mm
16mm
16mm
AT212121/T 77mm
122mm
21mm
21mm
21mm
AT212821/T 82mm
152mm
21mm
21mm
28mm
AT281321/T 88mm
141mm
28mm
21mm
13mm
AT281328/T 88mm
129mm
28mm
28mm
13mm
AT281621/T 90mm
141mm
28mm
21mm
16mm
AT281628/T 90mm
129mm
28mm
28mm
16mm
AT282121/T 93mm
141mm
28mm
21mm
21mm
AT282128/T 93mm
129mm
28mm
28mm
21mm
AT282828/T 82mm
129mm
28mm
28mm
28mm
AT341634/T 98mm
139mm
34mm
34mm
16mm
AT342128/T 104mm
150mm
34mm
28mm
21mm
AT342134/T 104mm
139mm
34mm
34mm
21mm
AT343434/T 91mm
139mm
34mm
34mm
34mm
To order quote part number, body colour & Elastomer colour, e.g. AT211316/T/BLY
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / PR / PADL / PF
IP66
Yes
IP67
Yes
IP68
Yes (4 bar 30mins)
IP69K
Yes
Temperature Range
Static Applications: -50ºC to +120ºC
Moving Applications: -45ºC to +120ºC
Fitting Characteristics
Approvals
E
D
C
A
C
D
E
B
Type T
3 Way ‘T’ Piece
21T
28T
34T
