Adaptaflex Product Catalogue |
LIT211GB 0715
2
Non-metallic conduit systems
Swivel Coupler & Panel Mounting Type FL/A - Adaptalok ATS
™
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / PR / PADL / PF
IP40
Yes
IP65
Yes
IP68
Yes (4 bar 30mins)
IP69K
Yes
Swivel Coupler - Adaptalok ATS
™
Straight PA66 Body - Swivel Coupler
/
For coupling to corrugated flexible conduit
Materials:
Polyamide (Nylon) 66/TPE /
Colour:
Black (BL) Only / Yellow (Y), Blue (B) Elastomer
Part No. Nominal Conduit Size
AT13/A/U 13mm
AT16/A/U 16mm
AT21/A/U 21mm
AT28/A/U 28mm
AT34/A/U 34mm
AT42/A/U 42mm
AT48/A/U 48mm
AT54/A/U 54mm
To order quote part number, body colour & Elastomer colour, e.g. AT21/A/U/BLB
Temperature Range
Static Applications: -50ºC to +120ºC
Moving Applications: -45ºC to +120ºC
Fitting Characteristics
Swivel Coupler
Straight PA66 Body
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / PR / PADL / PF
IP40
Yes
IP65
Yes
IP68
Yes (4 bar 30mins)
IP69K
Yes
Panel Mounting Type FL/A - Adaptalok ATS
™
Straight Panel Mounting-Swivel Flange
/
With integral face seal
Materials:
Polyamide (Nylon) 66/TPE /
Colour:
Black (BL), Grey (GR) / Yellow (Y), Blue (B) Elastomer
Part No.
Nominal Conduit Size
AT21/FL/A 21mm
AT28/FL/A 28mm
To order quote part number, body colour & Elastomer colour, e.g. AT21/FL/A/BLB
Temperature Range
Static Applications: -50ºC to +120ºC
Moving Applications: -45ºC to +120ºC
Fitting Characteristics
Panel Mounting Type FL/A
Straight Panel Mounting
Swivel Flange
Approvals
Blue Elastomer
Version Only
Approvals
Blue Elastomer
Version Only
