400A MCCB Panelboard
s )%#
s )CC K!
s )CW K! S s 0LATED BUSBARS
s /UTGOING DEVICES !n ! 30 !n ! 40
s )0 8 CONSTRUCTION
Description
Rating No. Ways Part No.
6 way MCCB panelboard
400A
6
PSPB406
12 way MCCB panelboard
400A
12
PSPB4012
18 way MCCB panelboard
400A
18
PSPB4018
Incoming devices for 400A MCCB panelboard
Incoming Devices to be ordered separately. 4P options are supplied with an additional
neutral link assembly.
Description
Breaking
capacity kA
Rating Poles Part No.
CH Frame Circuit breaker switch 50kA
250A 3
PSCH3250CB
CH Frame Circuit breaker switch 50kA
320A 3
PSCH3320CB
CH Frame Circuit breaker switch 50kA
400A 3
PSCH3400CB
CH Frame MCCB incomer
50kA
250A 3
PSCH3250MC
CH Frame MCCB incomer
50kA
320A 3
PSCH3320MC
CH Frame MCCB incomer
50kA
400A 3
PSCH3400MC
CH Frame MCCB incomer
50kA
250A 4
PSCH4250MC
CH Frame MCCB incomer
50kA
400A 4
PSCH4400MC
CH Frame Circuit Breaker Switch 50kA
400A 4
PSCH4400CB
Cable Extension Box for 400A Panelboard
Extension boxes can be mounted top or bottom and can be stacked as necessary. Corner
filler boxes to fill gaps when both side extension boxes and top/bottom extension boxes are
fitted to MCCB panelboard.
Description
Part No.
Cable extension box 250mm high
PSPB25EXTB
Universal Corner Filler Box
PSPBCFB
Surge Protection Kit for MCCB Panelboard
A metered side extension box must be used to house surge protection kit. Surge Protection
kit requires TP 125A MCCB (ordered separately. Please refer to page 41). For further
information on surge protection, please refer to pages 52-55.
Description
Part No.
Surge Protection kit – Type 1, 2 and 3
PSPB415M1
MCCB Panelboards
400A MCCB Panelboard
PSPB406
PSPB415M1
PSCH3400CB
