MCCB Panelboards
250A MCCB Panelboard
250A MCCB Panelboards
s )%#
s )CC K!
s )CW K! S s 0LATED BUSBARS
s /UTGOING DEVICES ! ! 30 AND ! ! 40
s )0 8 CONSTRUCTION
Description
Rating No. Ways Part No.
4 way MCCB panelboard
250A
4
PSPB254
6 way MCCB panelboard
250A
6
PSPB256
8 way MCCB panelboard
250A
8
PSPB258
12 way MCCB panelboard
250A
12
PSPB2512
Incoming devices for 250A MCCB panelboard
Incoming Devices to be ordered separately. 4P options are supplied with an additional
neutral link assembly.
Description
Breaking Capacity kA No. Ways Poles Part No.
Circuit breaker switch 25kA
160A
3
PSFN3160CB
Circuit breaker switch 25kA
200A
3
PSFN3200CB
Circuit breaker switch 25kA
250A
3
PSFN3250CB
MCCB incomer
25kA
160A
3
PSFN3160MC
MCCB incomer
25kA
200A
3
PSFN3200MC
MCCB incomer
25kA
250A
3
PSFN3250MC
MCCB incomer
25kA
160A
4
PSFN4160MC
MCCB incomer
25kA
200A
4
PSFN4200MC
MCCB incomer
25kA
250A
4
PSFN4250MC
Circuit Breaker Switch 25kA
250A
4
PSFN4250CB
Cable Extension Boxes for 250A Panelboard
Extension boxes can be mounted top or bottom and can be stacked as necessary.
Corner filler boxes to fill gaps when both side extension boxes and top/bottom extension
boxes are fitted to MCCB panelboard.
Description
Part No.
Cable extension box 250mm high
PSPB25EXTB
Universal Corner Filler Box
PSPBCFB
Surge Protection Kit for MCCB
A side extension box with hinged door and cut outs must be used to house surge protection
kit. For further information on surge protection, please refer to pages 52-55.
Requires TP 125A MCCB (please order separately - see page 38).
Description
Part No.
Surge Protection kit – Type 1, 2 and 3*
PSPB415M1
* Fit SPD in left hand side extension box.
PSPB256
PSFN3200CB
PSPB415M1
