PowerSafe – Commercial & Industrial
35
MCCB Panelboards
Quality Features
s Removable door with easy align hinge design, to aid installation
s Rigid construction to reduce distortion during installation
s Plated busbars
s Full Form MCCB blanking modules for unused ways for increase safety
s Plug connectable voltage reference fuses pre-installed for easy meter installation
s Comprehensive range of surge protection and metering solutions
MCCB Panelboard General Characteristics
250A
400A
630A
IP Rating
Paint Specification
Conditional Short Circuit Rating
Short Circuit Withstand Rating
Forms of Separation
IP3X
RAL 7035 epoxy powder coating
35kA to BS EN 61439-1
30kA – 1s to BS EN 61439-1
Form 3b
IP3X
RAL 7035 epoxy powder coating
50kA to BS EN 61439-1
30kA – 1s to BS EN 61439-1
Form 3b
IP3X
RAL 7035 epoxy powder coating
50kA to BS EN 61439-1
50kA – 1s to BS EN 61439-1
Form 3b
Cable Capacities
MCCB/SwD incoming device
Incoming earth terminal
Incoming neutral terminal
Outgoing earth terminal
Outgoing neutral terminal
MCCB outgoing device
120mm
2
max*
M10
M8
50mm
2
(16)
50mm
2
(16)
16A-160A = 70mm
2
2 x 240mm
2
** (M12 stud)
M10
M8
50mm
2
(18)
50mm
2
(20)
16A-160A = 70mm
2
2 x 240mm
2
*** (M12 stud)
M10
M12
70mm
2
(18)
70mm
2
(20)
16A-160A = 70mm
2
200-250A = 150mm
2
A complete range of MCCB Panelboards for Electrical supplies from 250A – 630A. Outgoing MCCB’s for current ratings up
to 160A are available for Panelboards up to 400A. The 630A Panelboards provide options for outgoing circuits up to 250A. In
addition to managing safe Electrical Distribution, the range reflects the wider peripheral demands within modern Commercial
buildings installations and upgrades, addressing application requirements such as metering and surge protection.
* Recommended 120mm
2
with Cage Clamp
** Recommended 1 x 240mm
2
*** Recommended 2 x 185mm
2
